HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032112121

HC-Cargo Alternator

Technical info:

Voltage: 14, Amper: 70, Rotation: CW, Mounting bracket distributor: 55.50

Description

Voltage: 14
Amp: 70
Terminal: W
Pulley dist.: 33.00
Width/holder arm: 14.40
Mounting bracket dist.: 55.50
Bracket hole: 8.40
Belt adjustment bracket hole position.: 50
Belt adjustment bracket hole 1: M8
Pulley diameter: 62.00
Grooves/pulley: 5
Radius: 81.00
Radius 2: 85.00
B+: M6
Position/B+ in min.: 5
D+ Size: M5
Rotation: CW
Plug number: PL70
W plug type: M5
Total length mm: 178.00
Pulley: SP
Voltage regulator type: IR
Product information: BN
Servicing: Ford

Files

  • OEM
    F032112121, r97ab10300ad, R97AB10300AE, R97AB10300AE1, 1E07-18-400, 95VW4A286BA, 96FF10300DB, 96ff10300dc, 97ab10300aa, 97ab10300ab, 97ab10300ac, 97ab10300ad, 97ab10300ae, 1217ir, 1986A01306, 1001869, 1015821, 1032139, 1066047, 1066407, 1071383, 1107446, 1136152, 1406095, 63321244, 63321669, 63321691, 63321724, 63321730, 63321730a, 63321730b, 63341244, 63341669, 63341691, 63341724, 63341730

  • Normalised article numbler
    a4005, a6262denso, alt10003, alt12011, alt12076, alt4215, bao3185, cal30106, dan047, dendan047, dra3536, f032112121, f042307009, f042a07009, fra803, lrb00243, man938, mg728, qa2122, r97ab10300ad, r97ab10300ae, r97ab10300ae1, 1e0718400, 8el011360731, 8el011710211, 8el737285001, 95vw4a286ba, 96ff10300db, 96ff10300dc, 97ab10300aa, 97ab10300ab, 97ab10300ac, 97ab10300ad, 97ab10300ae, 1217ir, 1986a01306, 4568, 5647, 21243n, 56521, 119247, 119596, 200109, 210010, 210010a, 282662, 301217ri, 437756, 443025, 746033, 746833, 1001869, 1015821, 1032139, 1066047, 1066407, 1071383, 1107446, 1136152, 1406095, 12044630, 32044631, 63321244, 63321669, 63321691, 63321724, 63321730, 63321730a, 63321730b, 63341244, 63341669, 63341691, 63341724, 63341730, 219137702, 0986044631, 063341730010, 944390900410
  • Description
    Voltage: 14
    Amp: 70
    Terminal: W
    Pulley dist.: 33.00
    Width/holder arm: 14.40
    Mounting bracket dist.: 55.50
    Bracket hole: 8.40
    Belt adjustment bracket hole position.: 50
    Belt adjustment bracket hole 1: M8
    Pulley diameter: 62.00
    Grooves/pulley: 5
    Radius: 81.00
    Radius 2: 85.00
    B+: M6
    Position/B+ in min.: 5
    D+ Size: M5
    Rotation: CW
    Plug number: PL70
    W plug type: M5
    Total length mm: 178.00
    Pulley: SP
    Voltage regulator type: IR
    Product information: BN
    Servicing: Ford

    Files

  • Suitable for these vehicles

    • OEM
      F032112121, r97ab10300ad, R97AB10300AE, R97AB10300AE1, 1E07-18-400, 95VW4A286BA, 96FF10300DB, 96ff10300dc, 97ab10300aa, 97ab10300ab, 97ab10300ac, 97ab10300ad, 97ab10300ae, 1217ir, 1986A01306, 1001869, 1015821, 1032139, 1066047, 1066407, 1071383, 1107446, 1136152, 1406095, 63321244, 63321669, 63321691, 63321724, 63321730, 63321730a, 63321730b, 63341244, 63341669, 63341691, 63341724, 63341730

    • Normalised article numbler
      a4005, a6262denso, alt10003, alt12011, alt12076, alt4215, bao3185, cal30106, dan047, dendan047, dra3536, f032112121, f042307009, f042a07009, fra803, lrb00243, man938, mg728, qa2122, r97ab10300ad, r97ab10300ae, r97ab10300ae1, 1e0718400, 8el011360731, 8el011710211, 8el737285001, 95vw4a286ba, 96ff10300db, 96ff10300dc, 97ab10300aa, 97ab10300ab, 97ab10300ac, 97ab10300ad, 97ab10300ae, 1217ir, 1986a01306, 4568, 5647, 21243n, 56521, 119247, 119596, 200109, 210010, 210010a, 282662, 301217ri, 437756, 443025, 746033, 746833, 1001869, 1015821, 1032139, 1066047, 1066407, 1071383, 1107446, 1136152, 1406095, 12044630, 32044631, 63321244, 63321669, 63321691, 63321724, 63321730, 63321730a, 63321730b, 63341244, 63341669, 63341691, 63341724, 63341730, 219137702, 0986044631, 063341730010, 944390900410
