HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032116143

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 220, Rotation: CW, Mounting bracket distributor: 52.00

Description

Voltage: 14
Amp: 220
Pulley: Distributor → Pulley dist.: 40.00
Width/holder arm: 90.00
Mount. bracket dist.: 52.00
Bracket hole: 8.10x9.70
Bracket hole 2: 9.00
Belt. adj. bracket hole 1: 8.00
Belt. adj. bracket hole 2: 9.00
Pulley dia.: 50.00
Grooves/pulley: 8
Radius: 83.00
Radius 2: 82.00
B+: M8
Position/B+ in min.: 15
Rotation: CW
Plug no.: PL166
Total length mm: 184.00
Terminal type: COM
Communication: LIN
Pulley: SP/FW
Regulator: IR
Remarks: This Alternator has a COM terminal on the Voltage regulator. It is recommended that the OEM number is used to check suitability before ordering.

Files

  • OEM
    a6291500050, A629150005080, F032116143, 0121813004, 0121813104, 6291500050, 629150005080

  • Normalised article numbler
    a6291500050, a629150005080, cal10407, drb7620, f032116143, 285901, 12047620, 0121813004, 0121813104, 555520220, 0986047620, 0986047623, 6291500050, 629150005080
  • Description
    Voltage: 14
    Amp: 220
    Pulley: Distributor → Pulley dist.: 40.00
    Width/holder arm: 90.00
    Mount. bracket dist.: 52.00
    Bracket hole: 8.10x9.70
    Bracket hole 2: 9.00
    Belt. adj. bracket hole 1: 8.00
    Belt. adj. bracket hole 2: 9.00
    Pulley dia.: 50.00
    Grooves/pulley: 8
    Radius: 83.00
    Radius 2: 82.00
    B+: M8
    Position/B+ in min.: 15
    Rotation: CW
    Plug no.: PL166
    Total length mm: 184.00
    Terminal type: COM
    Communication: LIN
    Pulley: SP/FW
    Regulator: IR
    Remarks: This Alternator has a COM terminal on the Voltage regulator. It is recommended that the OEM number is used to check suitability before ordering.

    Files

  • Suitable for these vehicles

    • OEM
      a6291500050, A629150005080, F032116143, 0121813004, 0121813104, 6291500050, 629150005080

    • Normalised article numbler
      a6291500050, a629150005080, cal10407, drb7620, f032116143, 285901, 12047620, 0121813004, 0121813104, 555520220, 0986047620, 0986047623, 6291500050, 629150005080
