HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115433

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 140, Rotation: CW, Mounting bracket distance: 61.50

Description

Alternator 12V-140A (VAG) 12V - 140A, 6 grooves, (COM) Original type = 90-620-8117 For Yourex product order 90-620-8116

Voltage: 14
Amperes: 140
Pulley diameter: 40.20
Width/holder arm: 14.30
Mounting bracket diameter: 61.50
Bracket hole: 9.50
Belt adjustment bracket hole position: 45
Belt adjustment bracket hole 1: 9.50
Belt adjustment bracket hole 2: M8
Pulley diameter: 60.00
Grooves/pulley: 6
Radius: 90.00
Radius 2: 90.00
B+: M8
Position/B+ in minutes: 60
Rotation: CW
Plug number: PL86
Total length mm: 200.00
Terminal type: COM
Communication: LIN
Pulley: SP/FW
Regulator type: IR
Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

Files

  • OEM
    A0446, A0446PR, A0446S, A211 320 00 26, A3273, A3273(VALEO), A3273PR, CAL10395, CAL15457, DRA0353, F000BL0861, F000BL0862, F032115433, F042301220, F042A01220, TG14C 031, 03F903023A, 03F903023D, 03F903023DX, 03F903023F, 03F903023FX, 03F903023J, 03L 903 023, 03L 903 023A, 03L 903023AX, 03L903023B, 03L903023BX, 03L903023D, 03L903023DX, 03L903023X, 03L903024F, 03L903024FX, 03L903024K, 03L903024KX, 03L903024M, 03L903024MX, 03L906023, 3L903023, 3L903023A, 3L903023B, 3L903023BX, 3L903023X, 3L903024M, 04B903023B, 04B903023BX, 04B903023D, 04B903023DX, 04B903024, 04B903024X, 04E903025J, 04E903025JX, 8EL012430-291, 0124 525 187, 0124 525 542, 305.582.140, 0986 081 160, 1986A00905, 11721N, 115433, 210927, 210927A, 302011RI, 440314, 2608901, 12090337, 32081160, 0124525187, 0124525542, 0986081160, 2113200026

  • Normalised article numbler
    a0446, a0446pr, a0446s, a2113200026, a3273, a3273pr, a3273valeo, cal10395, cal15457, dra0353, f000bl0861, f000bl0862, f032115433, f042301220, f042a01220, tg14c031, 03f903023a, 03f903023d, 03f903023dx, 03f903023f, 03f903023fx, 03f903023j, 03l903023, 03l903023a, 03l903023ax, 03l903023b, 03l903023bx, 03l903023d, 03l903023dx, 03l903023x, 03l903024f, 03l903024fx, 03l903024k, 03l903024kx, 03l903024m, 03l903024mx, 03l906023, 3l903023, 3l903023a, 3l903023b, 3l903023bx, 3l903023x, 3l903024m, 04b903023b, 04b903023bx, 04b903023d, 04b903023dx, 04b903024, 04b903024x, 04e903025j, 04e903025jx, 8el012430291, 1986a00905, 11721n, 115433, 210927, 210927a, 302011ri, 440314, 2608901, 12090337, 32081160, 0124525187, 0124525542, 305582140, 0986081160, 2113200026
  • Description
    Alternator 12V-140A (VAG) 12V - 140A, 6 grooves, (COM) Original type = 90-620-8117 For Yourex product order 90-620-8116

    Voltage: 14
    Amperes: 140
    Pulley diameter: 40.20
    Width/holder arm: 14.30
    Mounting bracket diameter: 61.50
    Bracket hole: 9.50
    Belt adjustment bracket hole position: 45
    Belt adjustment bracket hole 1: 9.50
    Belt adjustment bracket hole 2: M8
    Pulley diameter: 60.00
    Grooves/pulley: 6
    Radius: 90.00
    Radius 2: 90.00
    B+: M8
    Position/B+ in minutes: 60
    Rotation: CW
    Plug number: PL86
    Total length mm: 200.00
    Terminal type: COM
    Communication: LIN
    Pulley: SP/FW
    Regulator type: IR
    Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

    Files

  • Suitable for these vehicles

    • OEM
      A0446, A0446PR, A0446S, A211 320 00 26, A3273, A3273(VALEO), A3273PR, CAL10395, CAL15457, DRA0353, F000BL0861, F000BL0862, F032115433, F042301220, F042A01220, TG14C 031, 03F903023A, 03F903023D, 03F903023DX, 03F903023F, 03F903023FX, 03F903023J, 03L 903 023, 03L 903 023A, 03L 903023AX, 03L903023B, 03L903023BX, 03L903023D, 03L903023DX, 03L903023X, 03L903024F, 03L903024FX, 03L903024K, 03L903024KX, 03L903024M, 03L903024MX, 03L906023, 3L903023, 3L903023A, 3L903023B, 3L903023BX, 3L903023X, 3L903024M, 04B903023B, 04B903023BX, 04B903023D, 04B903023DX, 04B903024, 04B903024X, 04E903025J, 04E903025JX, 8EL012430-291, 0124 525 187, 0124 525 542, 305.582.140, 0986 081 160, 1986A00905, 11721N, 115433, 210927, 210927A, 302011RI, 440314, 2608901, 12090337, 32081160, 0124525187, 0124525542, 0986081160, 2113200026

    • Normalised article numbler
      a0446, a0446pr, a0446s, a2113200026, a3273, a3273pr, a3273valeo, cal10395, cal15457, dra0353, f000bl0861, f000bl0862, f032115433, f042301220, f042a01220, tg14c031, 03f903023a, 03f903023d, 03f903023dx, 03f903023f, 03f903023fx, 03f903023j, 03l903023, 03l903023a, 03l903023ax, 03l903023b, 03l903023bx, 03l903023d, 03l903023dx, 03l903023x, 03l903024f, 03l903024fx, 03l903024k, 03l903024kx, 03l903024m, 03l903024mx, 03l906023, 3l903023, 3l903023a, 3l903023b, 3l903023bx, 3l903023x, 3l903024m, 04b903023b, 04b903023bx, 04b903023d, 04b903023dx, 04b903024, 04b903024x, 04e903025j, 04e903025jx, 8el012430291, 1986a00905, 11721n, 115433, 210927, 210927a, 302011ri, 440314, 2608901, 12090337, 32081160, 0124525187, 0124525542, 305582140, 0986081160, 2113200026
