HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115587

HC-Cargo Alternator

Technical info:

Voltage: 14, Amperage: 120, Rotation: CW, Mounting bracket distributor: 50.50

Description

Hyundai/Kia Alternator 12V-120A 12V - 120A, 5 teeth (C, L, DF) 5 teeth (C, L, DF) For Your product order 90-228-2060

Voltage: 14
Amperage: 120
Pulley diameter: 32.50
Width/holder arm: 13.00
Mounting bracket distance: 50.50
Bracket hole: 10.50
Belt adjustment bracket hole position: 9
Belt adjustment bracket hole 1: 10.50
Pulley diameter: 56.00
Grooves/pulley: 5
Radius: 86.00
Radius 2: 97.00
B+: M8
Position/B+ in min.: 40
D+ Size: Plug
Rotation: CW
Plug no.: PL176
Total length mm: 175.00
Communication: PWM
Pulley: SP/FW
Regulator type: IR
Product info: BN/OE

Files

  • OEM
    F032115587, TG12C 090, TG12C 118, TG12C 140, TG12C 141, TG12C090, TG12C118, TG12C140, TG12C141, 2133ir, 37300-2A400, 37300-2A401, 37300-2A450, 37300-2A460, 37300-2A600, 37300-2a600, 37300-2A601, 37300-2A650, 37300-2A651, 115587, 439683, 440268, 2607316, 2607316A, 2616010, 2616019A, 2616021B

  • Normalised article numbler
    a3192, a3192valeo, a3543s, cal15383, cal15454, cal32169, dra0802, dra0989, dra0989n, dra1347, dra1347n, f032115587, lra03306, tg12c090, tg12c118, tg12c140, tg12c141, 2133ir, 20409n, 20409rw, 115587, 209026, 209026a, 209128, 209128a, 285918, 286905, 373002a400, 373002a401, 373002a450, 373002a460, 373002a600, 373002a601, 373002a650, 373002a651, 439683, 439760, 440268, 444354, 446765, 554309ri, 600205, 600716, 608366, 2607316, 2607316a, 2616010, 2616019a, 2616021b, 12061137, 12090644, 255509120, 0986083830, 2263011202, 2263101202, 2263161202
  • Description
    Hyundai/Kia Alternator 12V-120A 12V - 120A, 5 teeth (C, L, DF) 5 teeth (C, L, DF) For Your product order 90-228-2060

    Voltage: 14
    Amperage: 120
    Pulley diameter: 32.50
    Width/holder arm: 13.00
    Mounting bracket distance: 50.50
    Bracket hole: 10.50
    Belt adjustment bracket hole position: 9
    Belt adjustment bracket hole 1: 10.50
    Pulley diameter: 56.00
    Grooves/pulley: 5
    Radius: 86.00
    Radius 2: 97.00
    B+: M8
    Position/B+ in min.: 40
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL176
    Total length mm: 175.00
    Communication: PWM
    Pulley: SP/FW
    Regulator type: IR
    Product info: BN/OE

    Files

  • Suitable for these vehicles

    • OEM
      F032115587, TG12C 090, TG12C 118, TG12C 140, TG12C 141, TG12C090, TG12C118, TG12C140, TG12C141, 2133ir, 37300-2A400, 37300-2A401, 37300-2A450, 37300-2A460, 37300-2A600, 37300-2a600, 37300-2A601, 37300-2A650, 37300-2A651, 115587, 439683, 440268, 2607316, 2607316A, 2616010, 2616019A, 2616021B

    • Normalised article numbler
      a3192, a3192valeo, a3543s, cal15383, cal15454, cal32169, dra0802, dra0989, dra0989n, dra1347, dra1347n, f032115587, lra03306, tg12c090, tg12c118, tg12c140, tg12c141, 2133ir, 20409n, 20409rw, 115587, 209026, 209026a, 209128, 209128a, 285918, 286905, 373002a400, 373002a401, 373002a450, 373002a460, 373002a600, 373002a601, 373002a650, 373002a651, 439683, 439760, 440268, 444354, 446765, 554309ri, 600205, 600716, 608366, 2607316, 2607316a, 2616010, 2616019a, 2616021b, 12061137, 12090644, 255509120, 0986083830, 2263011202, 2263101202, 2263161202
