HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032116404

HC-Cargo Alternator

Technical info:

Voltage: 14, Amps: 150, Pulley diameter: 54.00, Radius: 90.00

Description

Voltage: 14
Amp: 150
Pulley: SP/FW
Pulley diameter: 54.00
Grooves/pulley: 6
Radius: 90.00
Radius 2: 90.00
B+: M8
Position/B+ in min.: 45
Plug no.: PL174
Total length mm: 198.00
Terminal type: COM
ID Code: 156
Communication: LIN
Regulator type: IR
Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

Files

  • OEM
    F032116404, 1986A00638, 104211-8540, 51907673

  • Normalised article numbler
    a6364, dan1145, f032116404, 1986a00638, 209333, 209333a, 287753, 849220, 12090690, 51907673, 0986085090, 1042118540
  • Description
    Voltage: 14
    Amp: 150
    Pulley: SP/FW
    Pulley diameter: 54.00
    Grooves/pulley: 6
    Radius: 90.00
    Radius 2: 90.00
    B+: M8
    Position/B+ in min.: 45
    Plug no.: PL174
    Total length mm: 198.00
    Terminal type: COM
    ID Code: 156
    Communication: LIN
    Regulator type: IR
    Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

    Files

  • Suitable for these vehicles

    • OEM
      F032116404, 1986A00638, 104211-8540, 51907673

    • Normalised article numbler
      a6364, dan1145, f032116404, 1986a00638, 209333, 209333a, 287753, 849220, 12090690, 51907673, 0986085090, 1042118540
