HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032114006

HC-Cargo Alternator

Technical info:

Voltage: 14, Amps: 90, Rotation: CW, Mounting bracket distributor: 38.00

Description

Toyota Yaris Alternator 12V-90A 12V - 90A, 6grooves (M, IG, L) Cars with European parts For Yourex product order 90-555-4921

Voltage: 14
Amp: 90
Pulley diameter: 48.00
Width/holder arm: 26.00
Mounting bracket distance: 38.00
Bracket hole: 10.00
Belt adjustment bracket hole position: 5
Belt adjustment bracket hole 1: M8
Pulley diameter: 55.00
Grooves/pulley: 6
Radius: 80.00
Radius 2: 90.00
B+: M6
Position/B+ in min.: 7
D+ size: Plug
Rotation: CW
Plug no.: PL67
Total length mm: 170.00
Pulley: SP
Regulator type: IR

Files

  • OEM
    F032114006, ja1800ir, 0986 049 211, 1986A01270, 27060-0J020, 27060-0J040, 102211-8010, 102211-8200, 114006

  • Normalised article numbler
    a6013, a6013pr, a6013sr, cal40163, dra0122, f032114006, ja1800ir, lea1098, 8el012428461, 1986a01270, 23277n, 112404, 114006, 209304, 209304a, 270600j020, 270600j040, 284907, 401800ri, 443163, 9212761, 12060856, 0986049211, 1022118010, 1022118200
  • Description
    Toyota Yaris Alternator 12V-90A 12V - 90A, 6grooves (M, IG, L) Cars with European parts For Yourex product order 90-555-4921

    Voltage: 14
    Amp: 90
    Pulley diameter: 48.00
    Width/holder arm: 26.00
    Mounting bracket distance: 38.00
    Bracket hole: 10.00
    Belt adjustment bracket hole position: 5
    Belt adjustment bracket hole 1: M8
    Pulley diameter: 55.00
    Grooves/pulley: 6
    Radius: 80.00
    Radius 2: 90.00
    B+: M6
    Position/B+ in min.: 7
    D+ size: Plug
    Rotation: CW
    Plug no.: PL67
    Total length mm: 170.00
    Pulley: SP
    Regulator type: IR

    Files

  • Suitable for these vehicles

    • OEM
      F032114006, ja1800ir, 0986 049 211, 1986A01270, 27060-0J020, 27060-0J040, 102211-8010, 102211-8200, 114006

    • Normalised article numbler
      a6013, a6013pr, a6013sr, cal40163, dra0122, f032114006, ja1800ir, lea1098, 8el012428461, 1986a01270, 23277n, 112404, 114006, 209304, 209304a, 270600j020, 270600j040, 284907, 401800ri, 443163, 9212761, 12060856, 0986049211, 1022118010, 1022118200
