HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032114215

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 75, Rotation: CW, Pulley diameter: 56.00

Description

Suzuki Liana Alternator 12V-75A 12V - 75A, 4 grooves, (C, IG, L) 12V - 75A, 4 grooves, (C, IG, L) For Yourex product order 90-528-2600

Voltage: 14
Amp: 75
Pulley diameter: 90.00
Width/holder arm: 56.00
Bracket hole: 10.50
Belt tensioner bracket hole position: 60
Belt tensioner bracket hole 1: M8
Pulley diameter: 56.00
Grooves/pulley: 4
Radius: 80.00
Radius 2: 83.00
B+: M8
Position/B+ in minutes: 5
Rotation: CW
Plug no.: PL95
Total length mm: 163.00
Pulley: SP
Regulator type: IR

Files

  • OEM
    F032114215, ja1803ir, 1986A01263, 31400-80G01, 31400-80G1, 31400-80G10, 31400-80G10AT0, 102211-2600, 114215

  • Normalised article numbler
    a6046, a6046denso, alth203, cal47106, dan1007, dendan1007, dra4283, f032114215, f042a0h203, ja1803ir, lra02270, 8el011711341, 1986a01263, 23270r, 114215, 210869, 210869a, 284751, 401803ri, 440900, 443074, 446536, 3140080g01, 3140080g1, 3140080g10, 3140080g10at0, 12060991, 0986082900, 1022112600, 063377530010
  • Description
    Suzuki Liana Alternator 12V-75A 12V - 75A, 4 grooves, (C, IG, L) 12V - 75A, 4 grooves, (C, IG, L) For Yourex product order 90-528-2600

    Voltage: 14
    Amp: 75
    Pulley diameter: 90.00
    Width/holder arm: 56.00
    Bracket hole: 10.50
    Belt tensioner bracket hole position: 60
    Belt tensioner bracket hole 1: M8
    Pulley diameter: 56.00
    Grooves/pulley: 4
    Radius: 80.00
    Radius 2: 83.00
    B+: M8
    Position/B+ in minutes: 5
    Rotation: CW
    Plug no.: PL95
    Total length mm: 163.00
    Pulley: SP
    Regulator type: IR

    Files

  • Suitable for these vehicles

    • OEM
      F032114215, ja1803ir, 1986A01263, 31400-80G01, 31400-80G1, 31400-80G10, 31400-80G10AT0, 102211-2600, 114215

    • Normalised article numbler
      a6046, a6046denso, alth203, cal47106, dan1007, dendan1007, dra4283, f032114215, f042a0h203, ja1803ir, lra02270, 8el011711341, 1986a01263, 23270r, 114215, 210869, 210869a, 284751, 401803ri, 440900, 443074, 446536, 3140080g01, 3140080g1, 3140080g10, 3140080g10at0, 12060991, 0986082900, 1022112600, 063377530010
