HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115306

HC-Cargo Alternator

Technical info:

Voltage: 14, Amps: 120, Rotation: CW, Mount. bracket dist.: 57.50

Description

Opel Alternator 12V-120A 12V - 120A, 5 grooves, (L, DFM) A - 56mm Opel Vectra from chassis number 71052537 Opel Astra from chassis numbers 72094719, 75086480, 78048188 For Yourex product order 90-430-4999

Voltage: 14
Amp: 120
Pulley dist.: 63.00
Width/holder arm: 23.00
Mounting bracket dist.: 57.50
Bracket hole: 10.50
Belt adjustment bracket hole pos.: 45
Belt adjustment bracket hole 1: 10.50
Pulley dia.: 53.50
Grooves/pulley: 5
B+: M8
Position/B+ in min.: 10
Rotation: CW
Plug no.: PL75
Pulley: SP
Prod. info: BN

Files

  • OEM
    F032115306, 0124 425 050, 0986 049 990, 1960ir, 1986A01484, 115306, 6204271, 13229985, 93190829, 0124425050

  • Normalised article numbler
    a0243, cal10504, dra1148, f032115306, 8el011712501, 1960ir, 1986a01484, 11475, 11475n, 115306, 209332, 209332a, 286513, 301960ri, 440875, 849161, 6204271, 12049990, 13229985, 93190829, 0124425050, 135575120, 0986049990, 0986049997
  • Description
    Opel Alternator 12V-120A 12V - 120A, 5 grooves, (L, DFM) A - 56mm Opel Vectra from chassis number 71052537 Opel Astra from chassis numbers 72094719, 75086480, 78048188 For Yourex product order 90-430-4999

    Voltage: 14
    Amp: 120
    Pulley dist.: 63.00
    Width/holder arm: 23.00
    Mounting bracket dist.: 57.50
    Bracket hole: 10.50
    Belt adjustment bracket hole pos.: 45
    Belt adjustment bracket hole 1: 10.50
    Pulley dia.: 53.50
    Grooves/pulley: 5
    B+: M8
    Position/B+ in min.: 10
    Rotation: CW
    Plug no.: PL75
    Pulley: SP
    Prod. info: BN

    Files

  • Suitable for these vehicles

    • OEM
      F032115306, 0124 425 050, 0986 049 990, 1960ir, 1986A01484, 115306, 6204271, 13229985, 93190829, 0124425050

    • Normalised article numbler
      a0243, cal10504, dra1148, f032115306, 8el011712501, 1960ir, 1986a01484, 11475, 11475n, 115306, 209332, 209332a, 286513, 301960ri, 440875, 849161, 6204271, 12049990, 13229985, 93190829, 0124425050, 135575120, 0986049990, 0986049997
