HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032113946

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 90, Rotation: CW, Mount. bracket dist.: 46.00

Description

Voltage: 14
Amp: 90
Pulley dist.: 42.50
Width/holder arm: 21.70
Mount. bracket dist.: 46.00
Bracket hole: 10.50
Bracket hole 2: M10
Belt. adj. brackethole pos.: 10
Belt. adj. bracket hole 1: 10.50
Belt. adj. bracket hole 2: M10
Pulley dia.: 54.00
Grooves/pulley: 6
Radius: 90.00
Radius 2: 90.00
B+: M8
Position/B+ in min.: 7
D+ Size: Plug
Rotation: CW
Plug no.: PL72
Total length mm: 150.50
Pulley: SP/FW
Regulator type: IR

Files

  • OEM
    F032113946, K9649611280, K9655296080, SG10B048, TG10B013, TG10B024, TG9B026, TG9B044, TG9B066, 1879ir, 1986A01341, 2542928, 2542928A, 2542938, 2542938A, 2543210, 2543210A, 2543522, 2543522A, 2543524, 2543524A, 2607212, 71786195, 9649611280, 9655296080, 9655858280

  • Normalised article numbler
    a3138, cal15338, cal15347, dra0067, dra0205, dra0205x, drb1461, f032113946, k9649611280, k9655296080, lra03080, lra03091, sg10b048, tg10b013, tg10b024, tg9b026, tg9b044, tg9b066, 8el011360421, 8el012426841, 8el738211561, 1879ir, 1986a01341, 4756, 5702g9, 5702h0, 5705cs, 5705na, 24078r, 24079n, 24079r, 112601, 112975, 200105, 200152, 210501, 210501a, 210507, 210507a, 210599, 210599a, 285692, 285703, 301879ri, 437550, 437584, 439553, 440279, 746148, 746150, 746948, 746950, 747015, 2542928, 2542928a, 2542938, 2542938a, 2543210, 2543210a, 2543522, 2543522a, 2543524, 2543524a, 2607212, 12090201, 12090276, 32080190, 71786195, 229134902, 229134972, 0986080190, 9649611280, 9655296080, 9655858280, 944390902130, 944390903720
  • Description
    Voltage: 14
    Amp: 90
    Pulley dist.: 42.50
    Width/holder arm: 21.70
    Mount. bracket dist.: 46.00
    Bracket hole: 10.50
    Bracket hole 2: M10
    Belt. adj. brackethole pos.: 10
    Belt. adj. bracket hole 1: 10.50
    Belt. adj. bracket hole 2: M10
    Pulley dia.: 54.00
    Grooves/pulley: 6
    Radius: 90.00
    Radius 2: 90.00
    B+: M8
    Position/B+ in min.: 7
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL72
    Total length mm: 150.50
    Pulley: SP/FW
    Regulator type: IR

    Files

  • Suitable for these vehicles

    • OEM
      F032113946, K9649611280, K9655296080, SG10B048, TG10B013, TG10B024, TG9B026, TG9B044, TG9B066, 1879ir, 1986A01341, 2542928, 2542928A, 2542938, 2542938A, 2543210, 2543210A, 2543522, 2543522A, 2543524, 2543524A, 2607212, 71786195, 9649611280, 9655296080, 9655858280

    • Normalised article numbler
      a3138, cal15338, cal15347, dra0067, dra0205, dra0205x, drb1461, f032113946, k9649611280, k9655296080, lra03080, lra03091, sg10b048, tg10b013, tg10b024, tg9b026, tg9b044, tg9b066, 8el011360421, 8el012426841, 8el738211561, 1879ir, 1986a01341, 4756, 5702g9, 5702h0, 5705cs, 5705na, 24078r, 24079n, 24079r, 112601, 112975, 200105, 200152, 210501, 210501a, 210507, 210507a, 210599, 210599a, 285692, 285703, 301879ri, 437550, 437584, 439553, 440279, 746148, 746150, 746948, 746950, 747015, 2542928, 2542928a, 2542938, 2542938a, 2543210, 2543210a, 2543522, 2543522a, 2543524, 2543524a, 2607212, 12090201, 12090276, 32080190, 71786195, 229134902, 229134972, 0986080190, 9649611280, 9655296080, 9655858280, 944390902130, 944390903720
