HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115385

HC-Cargo Alternator

Technical info:

Voltage: 28, Ammeter: 95, Rotation: CW, Mounting bracket distributor: 102.00

Description

Cat/Timberjack Alternator 24V-95A 24V - 95A, Self-exciting / Self-exciting Brushless. For Yourex product order 90-078-8340.

Voltage: 28
Amperage: 95
Terminal: W
Width/holder arm: 14.20
Mounting bracket distance: 102.00
Bracket hole: 13.00
Belt adjustment bracket hole position: 60
Belt adjustment bracket hole 1: 1/2" UNC
Radius: 99.50
Radius 2: 98.00
B+: 5/16" UNC
Position/B+ in minutes: 4
D+ Size: Plug
Rotation: CW
Total length mm: 230.00
Pulley: without
Regulator type: IR
Product info: BN

Files

  • OEM
    F032115385, OR4841, T 0R 4841, T 0R 4843, T 10R 9789, T 10R 9790, T 177-9953, T 197-8820, T 257-9466, 10R9789, 197-8820, 021080-0730, 101211-827, 101211-8270, 101211-8271, 101211-8272, 101211-8310, 101211-8340, 101211-8341, 115385

  • Normalised article numbler
    a6645s, cal40619, dan2003, dra0681, f032115385, or4841, t0r4841, t0r4843, t10r9789, t10r9790, t1779953, t1978820, t2579466, 10r9789, 11139, 12670, 12670n, 115385, 1978820, 101211827, 0210800730, 646024095, 1012118270, 1012118271, 1012118272, 1012118310, 1012118340, 1012118341
  • Description
    Cat/Timberjack Alternator 24V-95A 24V - 95A, Self-exciting / Self-exciting Brushless. For Yourex product order 90-078-8340.

    Voltage: 28
    Amperage: 95
    Terminal: W
    Width/holder arm: 14.20
    Mounting bracket distance: 102.00
    Bracket hole: 13.00
    Belt adjustment bracket hole position: 60
    Belt adjustment bracket hole 1: 1/2" UNC
    Radius: 99.50
    Radius 2: 98.00
    B+: 5/16" UNC
    Position/B+ in minutes: 4
    D+ Size: Plug
    Rotation: CW
    Total length mm: 230.00
    Pulley: without
    Regulator type: IR
    Product info: BN

    Files

  • Suitable for these vehicles

    • OEM
      F032115385, OR4841, T 0R 4841, T 0R 4843, T 10R 9789, T 10R 9790, T 177-9953, T 197-8820, T 257-9466, 10R9789, 197-8820, 021080-0730, 101211-827, 101211-8270, 101211-8271, 101211-8272, 101211-8310, 101211-8340, 101211-8341, 115385

    • Normalised article numbler
      a6645s, cal40619, dan2003, dra0681, f032115385, or4841, t0r4841, t0r4843, t10r9789, t10r9790, t1779953, t1978820, t2579466, 10r9789, 11139, 12670, 12670n, 115385, 1978820, 101211827, 0210800730, 646024095, 1012118270, 1012118271, 1012118272, 1012118310, 1012118340, 1012118341
