HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115383

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 200, Rotation: CW, Mount. bracket dist.: 57.00

Description

Alternator suitable for MB Vito 12V-200A 12V - 200A, 6-groove flywheel pulley, (COM-DFM) 6-groove flywheel pulley, (COM-DFM) Vehicles with automatic transmission For Yourex product order 90-365-4749

Voltage: 14
Amp: 200
Pulley distance: 30.50
Width/holder arm: 70.00
Mounting bracket distance: 57.00
Bracket hole: 10.00
Belt adjustment bracket hole 1: 9.50
Pulley diameter: 50.00
Grooves/pulley: 6
B+: M8
Position/B+ in min.: 43
Rotation: CW
Plug no.: PL114
Total length mm: 193.00
Terminal type: COM
Communication: BSS
Pulley: SP/FW
Regulator type: IR
Prod. info: BN
Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

Files

  • OEM
    A013154 2102, A0131542102, A013154210280, F032115383, 013 154 2102, 0124 625 022, 0986 047 490, 1840ir, 1986A00951, 115383, 0124625022, 0124625207, 0131542102, 013154210280

  • Normalised article numbler
    a0131542102, a013154210280, a0207, cal10256, drb7490, f032115383, 8el011712211, 8el738211351, 1840ir, 1986a00951, 4814, 23248n, 111840, 115383, 209050, 209050a, 285618, 301840ri, 443468, 9047490, 12047490, 32047490, 0124625022, 0124625207, 0131542102, 944390474, 0986047490, 0986047493, 2251772002, 013154210280, 944390474900
  • Description
    Alternator suitable for MB Vito 12V-200A 12V - 200A, 6-groove flywheel pulley, (COM-DFM) 6-groove flywheel pulley, (COM-DFM) Vehicles with automatic transmission For Yourex product order 90-365-4749

    Voltage: 14
    Amp: 200
    Pulley distance: 30.50
    Width/holder arm: 70.00
    Mounting bracket distance: 57.00
    Bracket hole: 10.00
    Belt adjustment bracket hole 1: 9.50
    Pulley diameter: 50.00
    Grooves/pulley: 6
    B+: M8
    Position/B+ in min.: 43
    Rotation: CW
    Plug no.: PL114
    Total length mm: 193.00
    Terminal type: COM
    Communication: BSS
    Pulley: SP/FW
    Regulator type: IR
    Prod. info: BN
    Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

    Files

  • Suitable for these vehicles

    • OEM
      A013154 2102, A0131542102, A013154210280, F032115383, 013 154 2102, 0124 625 022, 0986 047 490, 1840ir, 1986A00951, 115383, 0124625022, 0124625207, 0131542102, 013154210280

    • Normalised article numbler
      a0131542102, a013154210280, a0207, cal10256, drb7490, f032115383, 8el011712211, 8el738211351, 1840ir, 1986a00951, 4814, 23248n, 111840, 115383, 209050, 209050a, 285618, 301840ri, 443468, 9047490, 12047490, 32047490, 0124625022, 0124625207, 0131542102, 944390474, 0986047490, 0986047493, 2251772002, 013154210280, 944390474900
