HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032112355

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 80, Rotation: CW, Mounting bracket distance: 54.00

Description

Mitsubishi Diesel Alternator 12V-80A 12V - 80A, 2V, (S, L) Pulley 74mm in diameter! For Yourex product order 90-380-3118

Voltage: 14
Amp: 80
Pulley dist.: 42.00
Width/holder arm: 13.00
Mounting bracket dist.: 54.00
Bracket hole: 10.20
Belt adjustment bracket hole position: 3
Belt adjustment bracket hole 1: M8
Pulley dia.: 76.00
Grooves/pulley: 2
Radius: 90.00
Radius 2: 88.00
B+: M8
Position/B+ in min.: 5
D+ Size: Plug
Rotation: CW
Plug no.: PL07
Total length mm: 224.00
Pulley: DP
Fan: IF
Regulator type: IR
Vacuum pump: Yes
Prod. info: BN
Servicing: Mitsubishi

Files

  • OEM
    A002TN1798, A002TN1798A, A002TN1798AT, A002TN1798ZT, A2T N1798, A2T-N1798A, A2T-N1798ZT, a2tn1798, a2tn1798a, a2tn1798at, a2tn1798zt, F032112355, ja1533ir, MD 340419, MD 366052, md340419, md366052, 112355

  • Normalised article numbler
    a002tn1798, a002tn1798a, a002tn1798at, a002tn1798zt, a2tn1798, a2tn1798a, a2tn1798at, a2tn1798zt, a5025, alt31079, alth095, cal35166, dra0095, f032112355, f042a0h095, ja1533ir, lra01717, md340419, md366052, 8el011711181, 9340, 12644r, 111602, 112355, 119947, 210595, 210595a, 282980, 401533ri, 440984, 849164, 9051566, 12060748, 155604080, 526146802, 0986045601, 944390515660
  • Description
    Mitsubishi Diesel Alternator 12V-80A 12V - 80A, 2V, (S, L) Pulley 74mm in diameter! For Yourex product order 90-380-3118

    Voltage: 14
    Amp: 80
    Pulley dist.: 42.00
    Width/holder arm: 13.00
    Mounting bracket dist.: 54.00
    Bracket hole: 10.20
    Belt adjustment bracket hole position: 3
    Belt adjustment bracket hole 1: M8
    Pulley dia.: 76.00
    Grooves/pulley: 2
    Radius: 90.00
    Radius 2: 88.00
    B+: M8
    Position/B+ in min.: 5
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL07
    Total length mm: 224.00
    Pulley: DP
    Fan: IF
    Regulator type: IR
    Vacuum pump: Yes
    Prod. info: BN
    Servicing: Mitsubishi

    Files

  • Suitable for these vehicles

    • OEM
      A002TN1798, A002TN1798A, A002TN1798AT, A002TN1798ZT, A2T N1798, A2T-N1798A, A2T-N1798ZT, a2tn1798, a2tn1798a, a2tn1798at, a2tn1798zt, F032112355, ja1533ir, MD 340419, MD 366052, md340419, md366052, 112355

    • Normalised article numbler
      a002tn1798, a002tn1798a, a002tn1798at, a002tn1798zt, a2tn1798, a2tn1798a, a2tn1798at, a2tn1798zt, a5025, alt31079, alth095, cal35166, dra0095, f032112355, f042a0h095, ja1533ir, lra01717, md340419, md366052, 8el011711181, 9340, 12644r, 111602, 112355, 119947, 210595, 210595a, 282980, 401533ri, 440984, 849164, 9051566, 12060748, 155604080, 526146802, 0986045601, 944390515660
