HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032116433

HC-Cargo Alternator

Technical info:

Voltage: 28, Amp: 150, Rotation: CW, Mounting bracket distance: 107.00

Description

Generator 24V-150A 24V - 150A, 8 teeth, (W, L, 15, S, DFM) Volvo B11R & B13R chassis with 2 x 150A alternators For Yourex product order 90-600-5102

Voltage: 28
Amp: 150
Pulley distance: 44.50
Width/holder arm: 13.50
Mounting bracket distance: 107.00
Bracket hole: 13.00
Belt adjustment bracket hole position: 60
Belt adjustment bracket hole 1: 11.00
Pulley diameter: 62.00
Grooves/pulley: 8
Radius: 98.00
Radius 2: 98.00
B+: M8
Position/B+ in minutes: 2
D+ Size: Plug
Rotation: CW
Plug number: PL82
W plug type: Plug
Total length mm: 225.00
Pulley: SP
Regulator type: IR

Files

  • OEM
    F032116433, 0124 655 057, 0124 655 102, 1986A00557, 1986A01035, 116433, 20988293, 21561402, 0124655057, 0124655102, 0124655507

  • Normalised article numbler
    a0370, a0581s, cal10656, cal10667, f032116433, lra04338, 8el012584841, 1986a00557, 1986a01035, 116433, 202009, 443486, 444419, 487947, 553693ri, 12090746, 20988293, 21561402, 0124655057, 0124655102, 0124655507, 816508150, 0986085290
  • Description
    Generator 24V-150A 24V - 150A, 8 teeth, (W, L, 15, S, DFM) Volvo B11R & B13R chassis with 2 x 150A alternators For Yourex product order 90-600-5102

    Voltage: 28
    Amp: 150
    Pulley distance: 44.50
    Width/holder arm: 13.50
    Mounting bracket distance: 107.00
    Bracket hole: 13.00
    Belt adjustment bracket hole position: 60
    Belt adjustment bracket hole 1: 11.00
    Pulley diameter: 62.00
    Grooves/pulley: 8
    Radius: 98.00
    Radius 2: 98.00
    B+: M8
    Position/B+ in minutes: 2
    D+ Size: Plug
    Rotation: CW
    Plug number: PL82
    W plug type: Plug
    Total length mm: 225.00
    Pulley: SP
    Regulator type: IR

    Files

  • Suitable for these vehicles

    • OEM
      F032116433, 0124 655 057, 0124 655 102, 1986A00557, 1986A01035, 116433, 20988293, 21561402, 0124655057, 0124655102, 0124655507

    • Normalised article numbler
      a0370, a0581s, cal10656, cal10667, f032116433, lra04338, 8el012584841, 1986a00557, 1986a01035, 116433, 202009, 443486, 444419, 487947, 553693ri, 12090746, 20988293, 21561402, 0124655057, 0124655102, 0124655507, 816508150, 0986085290
