HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115703

HC-Cargo Alternator

Technical info:

Voltage: 14, Current: 150, Rotation: CW, Mounting bracket distributor: 81.00

Description

Nissan Navara Alternator 12V-150A 12V - 150A, 7 teeth, (C/PWM, S, L) for Yourex product order 90-400-2517 Voltage: 14 Amp: 150 Pulley distance: 38.50 Width/holder arm: 13.00 Mounting bracket distance: 81.00 Bracket hole: 10.50 Belt adjustment bracket hole position: 53 Belt adjustment bracket hole 1: 8.50 Pulley diameter: 65.00 Grooves/pulley: 7 Radius: 90.00 Radius 2: 85.00 B+: M8 Position/B+ in min.: 50 D+ Size: Plug Rotation: CW Plug no.: PL163 Total length mm: 173.00 Terminal type: L-S-C Pulley: SP/FW Fan: IF Regulator type: IR

Files

  • OEM
    A002TX1781, A2T-X1781, A2T-X1781AE, A2TX1781, A2TX1781AE, A2TX1781ZE, F032115703, 23100-1AT1A, 23100-1at1a, 23100-1AT3A, 23100-1AT6M, 115703, 7485146058

  • Normalised article numbler
    a002tx1781, a2tx1781, a2tx1781ae, a2tx1781ze, a5226, cal35309, dra1304, f032115703, f042205108, lra03628, 8el015630511, 21339r, 21339rw, 114114, 115703, 209519, 209519a, 231001at1a, 231001at3a, 231001at6m, 286738, 440673, 12061039, 165582150, 2273231502, 7485146058
  • Description
    Nissan Navara Alternator 12V-150A 12V - 150A, 7 teeth, (C/PWM, S, L) for Yourex product order 90-400-2517 Voltage: 14 Amp: 150 Pulley distance: 38.50 Width/holder arm: 13.00 Mounting bracket distance: 81.00 Bracket hole: 10.50 Belt adjustment bracket hole position: 53 Belt adjustment bracket hole 1: 8.50 Pulley diameter: 65.00 Grooves/pulley: 7 Radius: 90.00 Radius 2: 85.00 B+: M8 Position/B+ in min.: 50 D+ Size: Plug Rotation: CW Plug no.: PL163 Total length mm: 173.00 Terminal type: L-S-C Pulley: SP/FW Fan: IF Regulator type: IR

    Files

  • Suitable for these vehicles

    • OEM
      A002TX1781, A2T-X1781, A2T-X1781AE, A2TX1781, A2TX1781AE, A2TX1781ZE, F032115703, 23100-1AT1A, 23100-1at1a, 23100-1AT3A, 23100-1AT6M, 115703, 7485146058

    • Normalised article numbler
      a002tx1781, a2tx1781, a2tx1781ae, a2tx1781ze, a5226, cal35309, dra1304, f032115703, f042205108, lra03628, 8el015630511, 21339r, 21339rw, 114114, 115703, 209519, 209519a, 231001at1a, 231001at3a, 231001at6m, 286738, 440673, 12061039, 165582150, 2273231502, 7485146058
