HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115679

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 130, Rotation: CW, Pulley diameter: 53.80

Description

Dodge/Fiat Alternator 12V-130A 12V - 130A, 6groove.frt, ( - LIN - ) For Yourex product order 90-165-1840 Voltage: 14 Amp: 130 Pulley distance: 113.50 Width/holder arm: 61.50 Bracket hole: 14.00 Belt. adjust. bracket hole position: 59 Belt. adjust. bracket hole 1: 12.30 Pulley diameter: 53.80 Grooves/pulley: 6 Radius: 90.00 Radius 2: 90.00 B+: M8 Position/B+ in min.: 45 Rotation: CW Plug no.: PL154 Total length mm: 197.00 Terminal type: COM Communication: LIN Pulley: SP/FW Regulator type: IR Prod. info: BN Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

Files

  • OEM
    F032115679, K56029574 AA, K56029574AA, P56029574AA, TN104210-1840, 104210-1840, 115679, 56029574 AA, 56029574AA

  • Normalised article numbler
    a6217, a6217pr, a6218, cal40416, dra1496, f032115679, k56029574aa, lra03707, p56029574aa, tn1042101840, 20917, 115679, 209002, 209002a, 286768, 440981, 554099ri, 12090570, 56029574aa, 835921130, 835921150, 1042101840, 2183261302
  • Description
    Dodge/Fiat Alternator 12V-130A 12V - 130A, 6groove.frt, ( - LIN - ) For Yourex product order 90-165-1840 Voltage: 14 Amp: 130 Pulley distance: 113.50 Width/holder arm: 61.50 Bracket hole: 14.00 Belt. adjust. bracket hole position: 59 Belt. adjust. bracket hole 1: 12.30 Pulley diameter: 53.80 Grooves/pulley: 6 Radius: 90.00 Radius 2: 90.00 B+: M8 Position/B+ in min.: 45 Rotation: CW Plug no.: PL154 Total length mm: 197.00 Terminal type: COM Communication: LIN Pulley: SP/FW Regulator type: IR Prod. info: BN Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

    Files

  • Suitable for these vehicles

    • OEM
      F032115679, K56029574 AA, K56029574AA, P56029574AA, TN104210-1840, 104210-1840, 115679, 56029574 AA, 56029574AA

    • Normalised article numbler
      a6217, a6217pr, a6218, cal40416, dra1496, f032115679, k56029574aa, lra03707, p56029574aa, tn1042101840, 20917, 115679, 209002, 209002a, 286768, 440981, 554099ri, 12090570, 56029574aa, 835921130, 835921150, 1042101840, 2183261302
