HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032113919

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 125, Rotation: CW, Mount. bracket dist.: 60.70

Description

Voltage: 14
Amp: 125
Pulley dist.: 32.50
Width/holder arm: 14.20
Mount. bracket dist.: 60.70
Bracket hole: 8.50
Belt. adj. brackethole pos.: 45
Belt. adj. bracket hole 1: 8.50
Pulley dia.: 49.00
Grooves/pulley: 7
Radius: 90.00
Radius 2: 90.00
B+: M8
Position/B+ in min.: 50
D+ Size: Plug
Rotation: CW
Plug no.: PL72
Total length mm: 175.00
Terminal type: L-DFM
Pulley: SP
Regulator type: IR
Prod. info: BN

Files

  • OEM
    AAK5791, F032113919, SG12B052, SG12B081, SG12B098, SG12B109, 11.204.026, 1814ir, 1986A01197, 23100AW300, 2542554, 2542554D, 2542817, 2542817B, 2543337, 2543337A, 2543385, 7711135333, 8200086162, 8200290217, 8200495305, 8200538408

  • Normalised article numbler
    a3034, aak5791, alth175, cal15108, dra0006, dra0006x, f032113919, f042a0h175, ia1437, lra02837, mg76, sg12b052, sg12b081, sg12b098, sg12b109, 8el011360471, 8el012426811, 1814ir, 1986a01197, 4689, 23100aw300, 23837n, 112430, 200094, 210566, 210566a, 284919, 301814ri, 437437, 439478, 746096, 746896, 2542554, 2542554d, 2542817, 2542817b, 2543337, 2543337a, 2543385, 9212197, 11204026, 12090124, 32437437, 0986080270, 2303011252, 7711135333, 8200086162, 8200290217, 8200495305, 8200538408, 944390903910
  • Description
    Voltage: 14
    Amp: 125
    Pulley dist.: 32.50
    Width/holder arm: 14.20
    Mount. bracket dist.: 60.70
    Bracket hole: 8.50
    Belt. adj. brackethole pos.: 45
    Belt. adj. bracket hole 1: 8.50
    Pulley dia.: 49.00
    Grooves/pulley: 7
    Radius: 90.00
    Radius 2: 90.00
    B+: M8
    Position/B+ in min.: 50
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL72
    Total length mm: 175.00
    Terminal type: L-DFM
    Pulley: SP
    Regulator type: IR
    Prod. info: BN

    Files

  • Suitable for these vehicles

    • OEM
      AAK5791, F032113919, SG12B052, SG12B081, SG12B098, SG12B109, 11.204.026, 1814ir, 1986A01197, 23100AW300, 2542554, 2542554D, 2542817, 2542817B, 2543337, 2543337A, 2543385, 7711135333, 8200086162, 8200290217, 8200495305, 8200538408

    • Normalised article numbler
      a3034, aak5791, alth175, cal15108, dra0006, dra0006x, f032113919, f042a0h175, ia1437, lra02837, mg76, sg12b052, sg12b081, sg12b098, sg12b109, 8el011360471, 8el012426811, 1814ir, 1986a01197, 4689, 23100aw300, 23837n, 112430, 200094, 210566, 210566a, 284919, 301814ri, 437437, 439478, 746096, 746896, 2542554, 2542554d, 2542817, 2542817b, 2543337, 2543337a, 2543385, 9212197, 11204026, 12090124, 32437437, 0986080270, 2303011252, 7711135333, 8200086162, 8200290217, 8200495305, 8200538408, 944390903910
