HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032112640

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 100/105, Rotation: CW, Pulley dia.: 58.00

Description

GM USA Delco Alternator 12V-105A 12V - 105A, 6-groove (P-L-I-S), Internal/External Regulation 11 Same fixed in 140A version = GE-7861 HD For Yourex product order GE-7861

Voltage: 14
Amp: 100/105
Pulley diameter: 73.50
Width/holder arm: 51.00
Bracket hole: 10.30
Belt adjustment bracket hole position: 50
Belt adjustment bracket hole 1: M8
Pulley diameter: 58.00
Grooves/pulley: 6
Radius: 79.00
Radius 2: 78.00
B+: M6
Position/B+ in min.: 15
D+ Size: Plug
Rotation: CW
Plug no.: PL24
Pulley: SP
Regulator type: IR
Prod. info: BN
Servicing: Buick
Remarks: Replacing: CS130.

Files

  • OEM
    F032112640, GE-7861, GE-7861-11, GE-8165, GE-8165-11, RC 48921, 7861-11N, 8165-11N, 1101110, 1101111, 1101296, 1101582, 1101599, 1101600, 1101632, 1101633, 1101637, 1101645, 1101646, 1101647, 1105710, 1105711, 10463001, 10463002, 10463045, 10463148, 10463181, 10463212, 10463417, 10463424, 10463425, 10479906, 10479993, 10479994, 10479997, 10480086, 10480099

  • Normalised article numbler
    a1008, alt1010an, alt1329c, alt40005, bao3305, drz0151, f032112640, f042300122, f042300212, f042a00122, ge7861, ge786111, ge8165, ge816511, rc48921, 50939ri, 281951, 786111, 786111n, 788411, 816511n, 816511r, 1101110, 1101111, 1101296, 1101582, 1101599, 1101600, 1101632, 1101633, 1101637, 1101645, 1101646, 1101647, 1105710, 1105711, 1162833dr, 1162933dr, 1162934dr, 1176633dr, 2014532, 10463001, 10463002, 10463045, 10463148, 10463181, 10463212, 10463417, 10463424, 10463425, 10479906, 10479993, 10479994, 10479997, 10480086, 10480099, 20113230, 20113232, 20113233, 32992860, 201132331, 528102852, 2001231052, 5281021002, 5281251002
  • Description
    GM USA Delco Alternator 12V-105A 12V - 105A, 6-groove (P-L-I-S), Internal/External Regulation 11 Same fixed in 140A version = GE-7861 HD For Yourex product order GE-7861

    Voltage: 14
    Amp: 100/105
    Pulley diameter: 73.50
    Width/holder arm: 51.00
    Bracket hole: 10.30
    Belt adjustment bracket hole position: 50
    Belt adjustment bracket hole 1: M8
    Pulley diameter: 58.00
    Grooves/pulley: 6
    Radius: 79.00
    Radius 2: 78.00
    B+: M6
    Position/B+ in min.: 15
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL24
    Pulley: SP
    Regulator type: IR
    Prod. info: BN
    Servicing: Buick
    Remarks: Replacing: CS130.

    Files

  • Suitable for these vehicles

    • OEM
      F032112640, GE-7861, GE-7861-11, GE-8165, GE-8165-11, RC 48921, 7861-11N, 8165-11N, 1101110, 1101111, 1101296, 1101582, 1101599, 1101600, 1101632, 1101633, 1101637, 1101645, 1101646, 1101647, 1105710, 1105711, 10463001, 10463002, 10463045, 10463148, 10463181, 10463212, 10463417, 10463424, 10463425, 10479906, 10479993, 10479994, 10479997, 10480086, 10480099

    • Normalised article numbler
      a1008, alt1010an, alt1329c, alt40005, bao3305, drz0151, f032112640, f042300122, f042300212, f042a00122, ge7861, ge786111, ge8165, ge816511, rc48921, 50939ri, 281951, 786111, 786111n, 788411, 816511n, 816511r, 1101110, 1101111, 1101296, 1101582, 1101599, 1101600, 1101632, 1101633, 1101637, 1101645, 1101646, 1101647, 1105710, 1105711, 1162833dr, 1162933dr, 1162934dr, 1176633dr, 2014532, 10463001, 10463002, 10463045, 10463148, 10463181, 10463212, 10463417, 10463424, 10463425, 10479906, 10479993, 10479994, 10479997, 10480086, 10480099, 20113230, 20113232, 20113233, 32992860, 201132331, 528102852, 2001231052, 5281021002, 5281251002
