HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032110264

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 40, Rotation: CW, Mounting bracket distributor: 80.20

Description

Nissan Micra 83>, Alternator 12V - 40A For Yourex product order 90-400-3541

Voltage: 14
Amperage: 40
Pulley diameter: 41.50
Width/holder arm: 13.20
Mounting bracket diameter: 80.20
Bracket hole: 8.30
Belt adjustment bracket hole position: 60
Belt adjustment bracket hole 1: M8
Pulley diameter: 69.00
Grooves/pulley: 1
Radius: 78.00
Radius 2: 78.00
B+: M5
Position/B+ in min.: 17
D+ Size: Plug
Rotation: clockwise
Plug number: PL08
Total length mm: 159.00
Pulley: P
Regulator type: IR
Product info: BN
Servicing: Nissan

Files

  • OEM
    A001T02871, A001T22071, A001T22971, A001T22975, A001T24371, A001T24571, A001T32471, a1t02871, a1t22071, a1t22971, a1t22975, a1t24371, a1t24571, a1t32471, B310M01B15EX, F032110264, GE01-18-300A, ja105ir, lr135-107, lr135-108, lr135-132, lr135-133, lr135-61, lr135-61b, lr135-70, lr135-70b, lr138-01, LR140-132, lr140-132, LR140-133, lr140-133, 11-0264, 23100-01b00, 23100-01B05, 23100-01b05, 23100-01b10, 23100-01b15, 23100-03b00, 23100-03B05, 23100-06t10, 23100-10110, 23100-b9800, 23100-b9801, 23100-b9802, 23100-b9805, 23100-b9810, 23100-D1B15, 23100-Q4500, 1516836R

  • Normalised article numbler
    a001t02871, a001t22071, a001t22971, a001t22975, a001t24371, a001t24571, a001t32471, a1t02871, a1t22071, a1t22971, a1t22975, a1t24371, a1t24571, a1t32471, a5164, a5167, ada3212, ada327, ada335, al242x, alt31012, alth002, b310m01b15ex, cal20170, dra2431, dra5411, f032110264, f042a0h002, fra633, ge0118300a, ja105ir, lr135107, lr135108, lr135132, lr135133, lr13561, lr13561b, lr13570, lr13570b, lr13801, lr140132, lr140133, lra00227, lra00251, lra00685, lra01218, qa1719, va220, va221, 8el726261001, 5309, 12288n, 14231, 14231n, 14231r, 14255n, 23100b9800, 23100b9801, 23100b9802, 23100b9805, 23100b9810, 23100d1b15, 23100q4500, 40105ri, 55794, 56052, 110264, 111201, 210124, 210124a, 270521, 280576, 280807, 281522, 281794, 436505, 436507, 1111201, 1111201hi, 1111201mi, 1516836r, 2310001b00, 2310001b05, 2310001b10, 2310001b15, 2310003b00, 2310003b05, 2310006t10, 2851103, 2851114, 2851135, 12060225, 227103402, 0986032651, 0986035411, 2310010110
  • Description
    Nissan Micra 83>, Alternator 12V - 40A For Yourex product order 90-400-3541

    Voltage: 14
    Amperage: 40
    Pulley diameter: 41.50
    Width/holder arm: 13.20
    Mounting bracket diameter: 80.20
    Bracket hole: 8.30
    Belt adjustment bracket hole position: 60
    Belt adjustment bracket hole 1: M8
    Pulley diameter: 69.00
    Grooves/pulley: 1
    Radius: 78.00
    Radius 2: 78.00
    B+: M5
    Position/B+ in min.: 17
    D+ Size: Plug
    Rotation: clockwise
    Plug number: PL08
    Total length mm: 159.00
    Pulley: P
    Regulator type: IR
    Product info: BN
    Servicing: Nissan

    Files

  • Suitable for these vehicles

    • OEM
      A001T02871, A001T22071, A001T22971, A001T22975, A001T24371, A001T24571, A001T32471, a1t02871, a1t22071, a1t22971, a1t22975, a1t24371, a1t24571, a1t32471, B310M01B15EX, F032110264, GE01-18-300A, ja105ir, lr135-107, lr135-108, lr135-132, lr135-133, lr135-61, lr135-61b, lr135-70, lr135-70b, lr138-01, LR140-132, lr140-132, LR140-133, lr140-133, 11-0264, 23100-01b00, 23100-01B05, 23100-01b05, 23100-01b10, 23100-01b15, 23100-03b00, 23100-03B05, 23100-06t10, 23100-10110, 23100-b9800, 23100-b9801, 23100-b9802, 23100-b9805, 23100-b9810, 23100-D1B15, 23100-Q4500, 1516836R

    • Normalised article numbler
      a001t02871, a001t22071, a001t22971, a001t22975, a001t24371, a001t24571, a001t32471, a1t02871, a1t22071, a1t22971, a1t22975, a1t24371, a1t24571, a1t32471, a5164, a5167, ada3212, ada327, ada335, al242x, alt31012, alth002, b310m01b15ex, cal20170, dra2431, dra5411, f032110264, f042a0h002, fra633, ge0118300a, ja105ir, lr135107, lr135108, lr135132, lr135133, lr13561, lr13561b, lr13570, lr13570b, lr13801, lr140132, lr140133, lra00227, lra00251, lra00685, lra01218, qa1719, va220, va221, 8el726261001, 5309, 12288n, 14231, 14231n, 14231r, 14255n, 23100b9800, 23100b9801, 23100b9802, 23100b9805, 23100b9810, 23100d1b15, 23100q4500, 40105ri, 55794, 56052, 110264, 111201, 210124, 210124a, 270521, 280576, 280807, 281522, 281794, 436505, 436507, 1111201, 1111201hi, 1111201mi, 1516836r, 2310001b00, 2310001b05, 2310001b10, 2310001b15, 2310003b00, 2310003b05, 2310006t10, 2851103, 2851114, 2851135, 12060225, 227103402, 0986032651, 0986035411, 2310010110
