HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032114172

HC-Cargo Alternator

Technical info:

Voltage: 14, Amps: 65, Rotation: CW, Mounting bracket distributor: 64.50

Description

Voltage: 14
Amp: 65
Pulley distance: 42.00
Width/holder arm: 15.00
Mounting bracket distance: 64.50
Bracket hole: 8.20
Belt adjustment bracket hole position: 60
Belt adjustment bracket hole 1: M8
Pulley diameter: 69.00
Grooves/pulley: 1
Radius: 78.00
Radius 2: 78.00
B+: M8
Position/B+ in minutes: 60
Rotation: CW
Spark plug no.: PL77
Total length mm: 144.50
Pulley: P
Product info: BN

Files

  • Description
    Voltage: 14
    Amp: 65
    Pulley distance: 42.00
    Width/holder arm: 15.00
    Mounting bracket distance: 64.50
    Bracket hole: 8.20
    Belt adjustment bracket hole position: 60
    Belt adjustment bracket hole 1: M8
    Pulley diameter: 69.00
    Grooves/pulley: 1
    Radius: 78.00
    Radius 2: 78.00
    B+: M8
    Position/B+ in minutes: 60
    Rotation: CW
    Spark plug no.: PL77
    Total length mm: 144.50
    Pulley: P
    Product info: BN

    Files

  • Suitable for these vehicles
