HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032110804

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 90, Rotation: CW, Mounting bracket distributor: 77.40

Description

Voltage: 14
Amp: 90
Pulley dist.: 35.00
Width/holder arm: 13.40
Mount. bracket dist.: 77.40
Bracket hole: 8.50
Belt. adj. bracket hole position: 4
Belt. adj. bracket hole 1: M8
Pulley dia.: 65.00
Grooves/pulley: 4
Radius: 89.50
Radius 2: 87.50
B+: M6
Position/B+ in min.: 25
Rotation: CW
Plug no.: PL07
Total length mm: 160.00
Pulley: SPAliamer
Regulator type: IR
Prod. info: BN
Servicing: Dodge

Files

  • OEM
    a000b0441, A003T45691, A003T45693, A003T45693ZC, A003T45694, a3t45691, a3t45693, a3t45693zc, a3t45694, ab190025, ab190072, AB190119, F032110804, hab190120, ja684ir, M39882, md140750, md149750, MD153357, md153843, 37300-32134, 37300-32800, 37300-33100, 37300-33101, 37300-33102, 37300-33103, 37300-33110

  • Normalised article numbler
    a000b0441, a003t45691, a003t45693, a003t45693zc, a003t45694, a3355valeo, a3t45691, a3t45693, a3t45693zc, a3t45694, a5027, ab190025, ab190072, ab190119, aca952, al4008x, alt3041, alt31070, alt3518, cal32105, dra3145, dra3185, f032110804, f042303013, f042303075, f042a03013, f042a03075, hab190120, ja684ir, lea0452, lra02646, m39882, md140750, md149750, md153357, md153843, qa3035, 8el012426511, 8el730067001, 5369, 9025, 13289, 13289n, 13289r, 40684ri, 56457, 119147, 210379, 210379a, 281723, 436610, 439415, 600039, 600041, 1122701md, 1122701mi, 2751533, 9051532, 9213079, 12060149, 063532623, 226112902, 0986049900, 3730032134, 3730032800, 3730033100, 3730033101, 3730033102, 3730033103, 3730033110, 063532623010
  • Description
    Voltage: 14
    Amp: 90
    Pulley dist.: 35.00
    Width/holder arm: 13.40
    Mount. bracket dist.: 77.40
    Bracket hole: 8.50
    Belt. adj. bracket hole position: 4
    Belt. adj. bracket hole 1: M8
    Pulley dia.: 65.00
    Grooves/pulley: 4
    Radius: 89.50
    Radius 2: 87.50
    B+: M6
    Position/B+ in min.: 25
    Rotation: CW
    Plug no.: PL07
    Total length mm: 160.00
    Pulley: SPAliamer
    Regulator type: IR
    Prod. info: BN
    Servicing: Dodge

    Files

  • Suitable for these vehicles

    • OEM
      a000b0441, A003T45691, A003T45693, A003T45693ZC, A003T45694, a3t45691, a3t45693, a3t45693zc, a3t45694, ab190025, ab190072, AB190119, F032110804, hab190120, ja684ir, M39882, md140750, md149750, MD153357, md153843, 37300-32134, 37300-32800, 37300-33100, 37300-33101, 37300-33102, 37300-33103, 37300-33110

    • Normalised article numbler
      a000b0441, a003t45691, a003t45693, a003t45693zc, a003t45694, a3355valeo, a3t45691, a3t45693, a3t45693zc, a3t45694, a5027, ab190025, ab190072, ab190119, aca952, al4008x, alt3041, alt31070, alt3518, cal32105, dra3145, dra3185, f032110804, f042303013, f042303075, f042a03013, f042a03075, hab190120, ja684ir, lea0452, lra02646, m39882, md140750, md149750, md153357, md153843, qa3035, 8el012426511, 8el730067001, 5369, 9025, 13289, 13289n, 13289r, 40684ri, 56457, 119147, 210379, 210379a, 281723, 436610, 439415, 600039, 600041, 1122701md, 1122701mi, 2751533, 9051532, 9213079, 12060149, 063532623, 226112902, 0986049900, 3730032134, 3730032800, 3730033100, 3730033101, 3730033102, 3730033103, 3730033110, 063532623010
