HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032112993

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 130, Rotation: CW/CCW, Mounting bracket distance: 101.50

Description

Voltage: 14
Amp: 130
Terminal: W
Width/holder arm: 14.20
Mount. bracket dist.: 101.50
Bracket hole: 13.00
Belt. adj. brackethole pos.: 60
Belt. adj. bracket hole 1: 1/2" UNC
Radius: 98.00
Radius 2: 98.00
B+: 1/4" UNF
Position/B+ in min.: 50
Rotation: CW/CCW
W plug type: 10-24 UNC
Total length mm: 217.00
Pulley: w/o
Prod. info: BN
Servicing: Volvo
Info: Shaft: 7/8" = 22.255 mm
Remarks: Replacing: 21SI. Negative grounding. One-wire system. B+: 1/4".

Files

  • OEM
    F032112993, F3HT10300AA, F3HT10300BA, F3HT10300CA, F3HT10300HB, F3HZ10346H, F4HT10300DA, F4HT10300EA, F4HT10300FA, F4HT10300KA, F4PU10346BA, F5HZ10346A, F8ZU10300AA, gl332, gl358, 1117889, 1117914, 1117923, 1117957, 1117958, 1117959, 1117962, 1677974c91, 1677974c92, 1680859c91, 1680859c92, 3604666rx, 3918558, 19010120, 19010136, 19010137, 19010154, 19010157, 19010158, 19010159, 19010160, 19010161, 19010162, 19010163, 19010166

  • Normalised article numbler
    a1358, adr0011, alt1706, f032112993, f042304024, f042a04024, f3ht10300aa, f3ht10300ba, f3ht10300ca, f3ht10300hb, f3hz10346h, f4ht10300da, f4ht10300ea, f4ht10300fa, f4ht10300ka, f4pu10346ba, f5hz10346a, f8zu10300aa, gl332, gl358, 7501, 7564, 7670n, 7771n0g, 7771r0g, 7976r, 8027n, 201111, 291867, 726874, 1117889, 1117914, 1117923, 1117957, 1117958, 1117959, 1117962, 1191800dr, 1191800dr1, 1677974c91, 1677974c92, 1680859c91, 1680859c92, 3604666rx, 3918558, 19010120, 19010136, 19010137, 19010154, 19010157, 19010158, 19010159, 19010160, 19010161, 19010162, 19010163, 19010166, 20232101, 20232102, 20232111, 20232112, 90014058, 90014093, 645019115
  • Description
    Voltage: 14
    Amp: 130
    Terminal: W
    Width/holder arm: 14.20
    Mount. bracket dist.: 101.50
    Bracket hole: 13.00
    Belt. adj. brackethole pos.: 60
    Belt. adj. bracket hole 1: 1/2" UNC
    Radius: 98.00
    Radius 2: 98.00
    B+: 1/4" UNF
    Position/B+ in min.: 50
    Rotation: CW/CCW
    W plug type: 10-24 UNC
    Total length mm: 217.00
    Pulley: w/o
    Prod. info: BN
    Servicing: Volvo
    Info: Shaft: 7/8" = 22.255 mm
    Remarks: Replacing: 21SI. Negative grounding. One-wire system. B+: 1/4".

    Files

  • Suitable for these vehicles

    • OEM
      F032112993, F3HT10300AA, F3HT10300BA, F3HT10300CA, F3HT10300HB, F3HZ10346H, F4HT10300DA, F4HT10300EA, F4HT10300FA, F4HT10300KA, F4PU10346BA, F5HZ10346A, F8ZU10300AA, gl332, gl358, 1117889, 1117914, 1117923, 1117957, 1117958, 1117959, 1117962, 1677974c91, 1677974c92, 1680859c91, 1680859c92, 3604666rx, 3918558, 19010120, 19010136, 19010137, 19010154, 19010157, 19010158, 19010159, 19010160, 19010161, 19010162, 19010163, 19010166

    • Normalised article numbler
      a1358, adr0011, alt1706, f032112993, f042304024, f042a04024, f3ht10300aa, f3ht10300ba, f3ht10300ca, f3ht10300hb, f3hz10346h, f4ht10300da, f4ht10300ea, f4ht10300fa, f4ht10300ka, f4pu10346ba, f5hz10346a, f8zu10300aa, gl332, gl358, 7501, 7564, 7670n, 7771n0g, 7771r0g, 7976r, 8027n, 201111, 291867, 726874, 1117889, 1117914, 1117923, 1117957, 1117958, 1117959, 1117962, 1191800dr, 1191800dr1, 1677974c91, 1677974c92, 1680859c91, 1680859c92, 3604666rx, 3918558, 19010120, 19010136, 19010137, 19010154, 19010157, 19010158, 19010159, 19010160, 19010161, 19010162, 19010163, 19010166, 20232101, 20232102, 20232111, 20232112, 90014058, 90014093, 645019115
