HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032114192

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 200, Rotation: CW, Radius: 90.00

Description

Voltage: 14
Amp: 200
Terminal: W
Width/holder arm: 56.00
Bracket hole: 11.00
Belt. adj. bracket hole position: 50
Belt. adj. bracket hole 1: 11.00
Radius: 90.00
Radius 2: 90.00
B+: M8
Position/B+ in min.: 48
D+ Size: M5
Rotation: CW
W plug type: 6.30
Total length mm: 178.00
Pulley: w/o
Fan: IF
Regulator type: IR
Prod. info: BN

Files

  • OEM
    AAN5346, AAN5511, F032114192, F731900010010, F731900010070, 11.203.389, 11.204.187, 01182544, 1182544, 01183187, 01183485, 1183485, 01183608, 73327990, 84474354, 0124625058

  • Normalised article numbler
    a9171letrika, a9171s, aan5346, aan5511, cal21128, dra0735, dra0735n, f032114192, f731900010010, f731900010070, ia1215, lra03202, mg29, 8el015643011, 113016, 285814, 553651ri, 01182544, 1182544, 01183187, 01183485, 1183485, 01183608, 11203389, 11204187, 12091001, 73327990, 84474354, 0124625058, 635504200, 5881102002
  • Description
    Voltage: 14
    Amp: 200
    Terminal: W
    Width/holder arm: 56.00
    Bracket hole: 11.00
    Belt. adj. bracket hole position: 50
    Belt. adj. bracket hole 1: 11.00
    Radius: 90.00
    Radius 2: 90.00
    B+: M8
    Position/B+ in min.: 48
    D+ Size: M5
    Rotation: CW
    W plug type: 6.30
    Total length mm: 178.00
    Pulley: w/o
    Fan: IF
    Regulator type: IR
    Prod. info: BN

    Files

  • Suitable for these vehicles

    • OEM
      AAN5346, AAN5511, F032114192, F731900010010, F731900010070, 11.203.389, 11.204.187, 01182544, 1182544, 01183187, 01183485, 1183485, 01183608, 73327990, 84474354, 0124625058

    • Normalised article numbler
      a9171letrika, a9171s, aan5346, aan5511, cal21128, dra0735, dra0735n, f032114192, f731900010010, f731900010070, ia1215, lra03202, mg29, 8el015643011, 113016, 285814, 553651ri, 01182544, 1182544, 01183187, 01183485, 1183485, 01183608, 11203389, 11204187, 12091001, 73327990, 84474354, 0124625058, 635504200, 5881102002
