HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032114807

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 60, Rotation: CW, Pulley diameter: 74.00

Description

Voltage: 14
Amp: 60
Pulley dist.: 61.00
Width/holder arm: 29.00
Bracket hole: 10.50
Belt. adj. brackethole pos.: 60
Belt. adj. bracket hole 1: M8
Pulley dia.: 74.00
Grooves/pulley: 1
Radius: 78.50
Radius 2: 78.00
B+: M6
Position/B+ in min.: 15
D+ Size: Plug
Rotation: CW
Plug no.: PL10
Total length mm: 164.00
Terminal type: IG-L
Pulley: P
Regulator type: IR
Prod. info: BN

Files

  • OEM
    A001TA1777, a1ta1777, A1TA3677, F032114807, 1C011-64010, 1C011-64011, 3A651-74010

  • Normalised article numbler
    a001ta1777, a1ta1777, a1ta3677, a5163, cal35185, dra1137, f032114807, 1c01164010, 1c01164011, 3a65174010, 12318, 12318n, 12318r, 287510, 12061152, 583115602
  • Description
    Voltage: 14
    Amp: 60
    Pulley dist.: 61.00
    Width/holder arm: 29.00
    Bracket hole: 10.50
    Belt. adj. brackethole pos.: 60
    Belt. adj. bracket hole 1: M8
    Pulley dia.: 74.00
    Grooves/pulley: 1
    Radius: 78.50
    Radius 2: 78.00
    B+: M6
    Position/B+ in min.: 15
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL10
    Total length mm: 164.00
    Terminal type: IG-L
    Pulley: P
    Regulator type: IR
    Prod. info: BN

    Files

  • Suitable for these vehicles

    • OEM
      A001TA1777, a1ta1777, A1TA3677, F032114807, 1C011-64010, 1C011-64011, 3A651-74010

    • Normalised article numbler
      a001ta1777, a1ta1777, a1ta3677, a5163, cal35185, dra1137, f032114807, 1c01164010, 1c01164011, 3a65174010, 12318, 12318n, 12318r, 287510, 12061152, 583115602
