HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115545

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 200, Rotation: CW, Mount. bracket dist.: 107.00

Description

Voltage: 14
Amp: 200
Terminal: W
Width/holder arm: 14.00
Mounting bracket distance: 107.00
Belt adjustment bracket holing position: 60
Belt adjustment bracket hole 1: 1/2" UNC
Radius: 99.00
Radius 2: 99.00
B+: M8
Position/B+ in min.: 2
D+ Size: M5
Rotation: CW
W plug type: M5
Total length mm: 230.00
Pulley: w/o
Voltage regulator type: IR

Files

  • OEM
    F032115545, 1986A00962, 87715398, 0124625059, 0124625123, 0504338098, 504338098

  • Normalised article numbler
    f032115545, mg41, 1986a00962, 12881n, 87715398, 0124625059, 0124625123, 0504338098, 504338098, 635530200, 0986082553
  • Description
    Voltage: 14
    Amp: 200
    Terminal: W
    Width/holder arm: 14.00
    Mounting bracket distance: 107.00
    Belt adjustment bracket holing position: 60
    Belt adjustment bracket hole 1: 1/2" UNC
    Radius: 99.00
    Radius 2: 99.00
    B+: M8
    Position/B+ in min.: 2
    D+ Size: M5
    Rotation: CW
    W plug type: M5
    Total length mm: 230.00
    Pulley: w/o
    Voltage regulator type: IR

    Files

  • Suitable for these vehicles

    • OEM
      F032115545, 1986A00962, 87715398, 0124625059, 0124625123, 0504338098, 504338098

    • Normalised article numbler
      f032115545, mg41, 1986a00962, 12881n, 87715398, 0124625059, 0124625123, 0504338098, 504338098, 635530200, 0986082553
