HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115737

HC-Cargo Alternator

Technical info:

Voltage: 14, Amps: 130, Rotation: CW, Mounting bracket distributor: 43.00

Description

Voltage: 14
Ampere: 130
Pulley diameter: 42.50
Width/holder arm: 20.00
Mounting bracket diameter: 43.00
Bracket hole: 11.00
Belt adjustment bracket hole position: 53
Belt adjustment bracket hole 1: 11.00
Pulley diameter: 53.30
Grooves/pulley: 6
Radius: 90.00
Radius 2: 84.00
B+: M8
Position/B+ in minutes: 58
D+ size: Plug
Rotation: CW
Plug number: PL133
Total length mm: 188.00
Pulley: SP
Regulator type: IR
Product info: BN

Files

  • OEM
    F032115737, TG12C057, 02131-9152, 02131-9153, 02131-9330, 37300-3c120, 37300-3C170, 37300-3C250, 102211-3102, 102211-3240

  • Normalised article numbler
    a3339, a6354, cal41119, f032115737, tg12c057, 11191, 11191n, 11191r, 373003c120, 373003c170, 373003c250, 12061035, 021319152, 021319153, 021319330, 255512130, 1022113102, 1022113240
  • Description
    Voltage: 14
    Ampere: 130
    Pulley diameter: 42.50
    Width/holder arm: 20.00
    Mounting bracket diameter: 43.00
    Bracket hole: 11.00
    Belt adjustment bracket hole position: 53
    Belt adjustment bracket hole 1: 11.00
    Pulley diameter: 53.30
    Grooves/pulley: 6
    Radius: 90.00
    Radius 2: 84.00
    B+: M8
    Position/B+ in minutes: 58
    D+ size: Plug
    Rotation: CW
    Plug number: PL133
    Total length mm: 188.00
    Pulley: SP
    Regulator type: IR
    Product info: BN

    Files

  • Suitable for these vehicles

    • OEM
      F032115737, TG12C057, 02131-9152, 02131-9153, 02131-9330, 37300-3c120, 37300-3C170, 37300-3C250, 102211-3102, 102211-3240

    • Normalised article numbler
      a3339, a6354, cal41119, f032115737, tg12c057, 11191, 11191n, 11191r, 373003c120, 373003c170, 373003c250, 12061035, 021319152, 021319153, 021319330, 255512130, 1022113102, 1022113240
