HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032115837

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 70, Rotation: CW, Mounting bracket distributor: 80.50

Description

Voltage: 14
Amperage: 70
Terminal: W
Pulley distributor: 42.00
Width/holder arm: 13.00
Mounting bracket distance: 80.50
Bracket hole: 10.20
Belt adjustment bracket hole position: 60
Belt adjustment bracket hole 1: M8
Pulley diameter: 80.00
Grooves/pulley: 1
Radius: 90.00
Radius 2: 85.00
B+: M8
Position/B+ in min.: 50
D+ Size: M5
Rotation: CW
W plug type: Plug
Total length mm: 183.00
Pulley: P
Alternator type: IR
Remarks: Like HC-CARGO 111980

Files

  • OEM
    F032115837, 23100-69t60, 0123310052

  • Normalised article numbler
    a0787s, cal10313, cal45118, drb7200, f032115837, 284831, 440963, 2310069t60, 12060800, 0123310052, 165573070, 227183702, 0986047200
  • Description
    Voltage: 14
    Amperage: 70
    Terminal: W
    Pulley distributor: 42.00
    Width/holder arm: 13.00
    Mounting bracket distance: 80.50
    Bracket hole: 10.20
    Belt adjustment bracket hole position: 60
    Belt adjustment bracket hole 1: M8
    Pulley diameter: 80.00
    Grooves/pulley: 1
    Radius: 90.00
    Radius 2: 85.00
    B+: M8
    Position/B+ in min.: 50
    D+ Size: M5
    Rotation: CW
    W plug type: Plug
    Total length mm: 183.00
    Pulley: P
    Alternator type: IR
    Remarks: Like HC-CARGO 111980

    Files

  • Suitable for these vehicles

    • OEM
      F032115837, 23100-69t60, 0123310052

    • Normalised article numbler
      a0787s, cal10313, cal45118, drb7200, f032115837, 284831, 440963, 2310069t60, 12060800, 0123310052, 165573070, 227183702, 0986047200
