HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032116169

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 180, Rotation: CW, Mounting bracket distributor: 40.80

Description

Voltage: 14
Amp: 180
Pulley dist.: 31.00
Width/holder arm: 62.70
Mount. bracket dist.: 40.80
Bracket hole: 9.30
Belt. adj. bracket hole 1: 9.30
Pulley dia.: 49.00
Grooves/pulley: 7
Radius: 87.00
Radius 2: 87.00
B+: M8
Position/B+ in min.: 10
Rotation: CW
Plug no.: PL86
Total length mm: 179.00
Terminal type: COM
Communication: BSS
Alternator: SP/FW
Voltage regulator type: IR
Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

Files

  • OEM
    F00E100028, F032116169, 7560985, 7560986, 0121715018, 0121715118, 12317560985, 12317560986

  • Normalised article numbler
    a0461, cal10452, dra0471, f00e100028, f032116169, 11362n, 11362r, 113051, 286597, 553974ri, 7560985, 7560986, 12090543, 0121715018, 0121715118, 215549180, 0986048943, 2151951802, 12317560985, 12317560986
  • Description
    Voltage: 14
    Amp: 180
    Pulley dist.: 31.00
    Width/holder arm: 62.70
    Mount. bracket dist.: 40.80
    Bracket hole: 9.30
    Belt. adj. bracket hole 1: 9.30
    Pulley dia.: 49.00
    Grooves/pulley: 7
    Radius: 87.00
    Radius 2: 87.00
    B+: M8
    Position/B+ in min.: 10
    Rotation: CW
    Plug no.: PL86
    Total length mm: 179.00
    Terminal type: COM
    Communication: BSS
    Alternator: SP/FW
    Voltage regulator type: IR
    Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

    Files

  • Suitable for these vehicles

    • OEM
      F00E100028, F032116169, 7560985, 7560986, 0121715018, 0121715118, 12317560985, 12317560986

    • Normalised article numbler
      a0461, cal10452, dra0471, f00e100028, f032116169, 11362n, 11362r, 113051, 286597, 553974ri, 7560985, 7560986, 12090543, 0121715018, 0121715118, 215549180, 0986048943, 2151951802, 12317560985, 12317560986
