HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032116301

HC-Cargo Alternator

Technical info:

Voltage: 14, Amp: 100, Rotation: CW, Mounting bracket distributor: 37.00

Description

Voltage: 14
Amp: 100
Pulley distance: 29.00
Width/holder arm: 18.00
Mounting bracket distance: 37.00
Bracket hole: 11.00
Belt adjustment. bracket hole 1: M8
Pulley diameter: 67.00
Grooves/pulley: 6
Radius: 89.00
Radius 2: 82.00
B+: M6
Position/B+ in min.: 20
D+ Size: Plug
Rotation: CW
Plug no.: PL61
Total length mm: 181.00
Lamp type: Inactive
Pulley: SP/FW
Fan: IF

Files

  • OEM
    b000911980, F032116301, 1986A01659, 021080-2380, 27060-0Q190, 104210-3490, 104211-3490

  • Normalised article numbler
    a6599s, b000911980, cal40484, dan1320, dra1459, f032116301, 1986a01659, 270600q190, 287557, 554356ri, 12090791, 195987100, 0210802380, 1042103490, 1042113490
  • Description
    Voltage: 14
    Amp: 100
    Pulley distance: 29.00
    Width/holder arm: 18.00
    Mounting bracket distance: 37.00
    Bracket hole: 11.00
    Belt adjustment. bracket hole 1: M8
    Pulley diameter: 67.00
    Grooves/pulley: 6
    Radius: 89.00
    Radius 2: 82.00
    B+: M6
    Position/B+ in min.: 20
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL61
    Total length mm: 181.00
    Lamp type: Inactive
    Pulley: SP/FW
    Fan: IF

    Files

  • Suitable for these vehicles

    • OEM
      b000911980, F032116301, 1986A01659, 021080-2380, 27060-0Q190, 104210-3490, 104211-3490

    • Normalised article numbler
      a6599s, b000911980, cal40484, dan1320, dra1459, f032116301, 1986a01659, 270600q190, 287557, 554356ri, 12090791, 195987100, 0210802380, 1042103490, 1042113490
