HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032116663

HC-Cargo Alternator

Technical info:

Voltage: 14, Amperes: 150, Rotation: CW, Mounting bracket distributor: 47.00

Description

Voltage: 14
Amp: 150
Pulley dist.: 22.00
Width/holder arm: 49.80
Mount. bracket dist.: 47.00
Bracket hole: 11.30
Belt. adj. brackethole pos.: 8
Belt. adj. bracket hole 1: 10.20
Pulley dia.: 53.60
Grooves/pulley: 6
Radius: 82.00
Radius 2: 86.00
B+: M8
Rotation: CW
Plug no.: PL136
Total length mm: 171.00
Pulley: SP/FW
Fan: IF

Files

  • OEM
    F032116663, LR013843, lr013843, LR070953, LR073680, 104210-2810

  • Normalised article numbler
    a6560s, cal40397, dan1106, dra1527, f032116663, lr013843, lr070953, lr073680, lra03896, 8el015637591, 40269, 287506, 444256, 554346ri, 12061056, 455537150, 1042102810
  • Description
    Voltage: 14
    Amp: 150
    Pulley dist.: 22.00
    Width/holder arm: 49.80
    Mount. bracket dist.: 47.00
    Bracket hole: 11.30
    Belt. adj. brackethole pos.: 8
    Belt. adj. bracket hole 1: 10.20
    Pulley dia.: 53.60
    Grooves/pulley: 6
    Radius: 82.00
    Radius 2: 86.00
    B+: M8
    Rotation: CW
    Plug no.: PL136
    Total length mm: 171.00
    Pulley: SP/FW
    Fan: IF

    Files

  • Suitable for these vehicles

    • OEM
      F032116663, LR013843, lr013843, LR070953, LR073680, 104210-2810

    • Normalised article numbler
      a6560s, cal40397, dan1106, dra1527, f032116663, lr013843, lr070953, lr073680, lra03896, 8el015637591, 40269, 287506, 444256, 554346ri, 12061056, 455537150, 1042102810
