HC-Cargo Alternator
HC-Cargo Alternator
Article no.: F032113886

HC-Cargo Alternator

Technical info:

Voltage: 28, Amp: 50, Rotation: CW, Mounting bracket distributor: 70.00

Description

Voltage: 28
Amp: 50
Pulley dist.: 60.00
Width/holder arm: 13.00
Mount. bracket dist.: 70.00
Bracket hole: 14.50
Belt. adj. brackethole pos.: 60
Belt. adj. bracket hole 1: 12.40
Pulley dia.: 84.50
Grooves/pulley: 3
Radius: 110.00
Radius 2: 115.00
B+: M6
Position/B+ in min.: 55
D+ Size: Plug
Rotation: CW
Plug no.: PL07
Total length mm: 225.00
Pulley: SP
Regulator type: IR
Prod. info: BN

Files

  • OEM
    A004TU5486, A004TU9586, a4tu5485, a4tu5486, A4TU9586, AT263669, F032113886, 1-81200530-3, 1812005303, 1812005902, 1812005903

  • Normalised article numbler
    a004tu5486, a004tu9586, a4tu5485, a4tu5486, a4tu9586, a5162, a5179, at263669, cal35623, dra1431, f032113886, lra04534, 12744n, 487824, 488643, 90273276, 1812005303, 1812005902, 1812005903
  • Description
    Voltage: 28
    Amp: 50
    Pulley dist.: 60.00
    Width/holder arm: 13.00
    Mount. bracket dist.: 70.00
    Bracket hole: 14.50
    Belt. adj. brackethole pos.: 60
    Belt. adj. bracket hole 1: 12.40
    Pulley dia.: 84.50
    Grooves/pulley: 3
    Radius: 110.00
    Radius 2: 115.00
    B+: M6
    Position/B+ in min.: 55
    D+ Size: Plug
    Rotation: CW
    Plug no.: PL07
    Total length mm: 225.00
    Pulley: SP
    Regulator type: IR
    Prod. info: BN

    Files

  • Suitable for these vehicles

    • OEM
      A004TU5486, A004TU9586, a4tu5485, a4tu5486, A4TU9586, AT263669, F032113886, 1-81200530-3, 1812005303, 1812005902, 1812005903

    • Normalised article numbler
      a004tu5486, a004tu9586, a4tu5485, a4tu5486, a4tu9586, a5162, a5179, at263669, cal35623, dra1431, f032113886, lra04534, 12744n, 487824, 488643, 90273276, 1812005303, 1812005902, 1812005903
