HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032113960

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 0.9, No./teeth: 10, Rotation: CW

Description

PSA/Mini Starter motor 12V-0.9kW 12V - 0.9kW, 10/11k A - 60mm, B - 13mm Mini: for vehicles without start-stop function! For Yourrex product order 91-450-2197

Voltage: 12
kW: 0.9
Mounting flange: 64.00
Drive distance: 13.00
Mounting hole 4 mm: 9.00
Mounting hole 3 mm: M8
Mounting hole 1 mm: 9.00
Distance / back: 137.00
Distance / front: 48.50
Number / teeth: 10
B+: M8
Terminal 50: 4.80
Gear type: GR
Distance 2: 29.00
Distance 3: 46.00
Distance 4: 91.00
Distance in mm: 124.00
Rotation: CW
Total length in mm: 194.00
Info: A. Measure = 60.00-64.00 mm.
Number / mounting holes: 4 (2)

Files

  • OEM
    CS1417, CST10424, CST35245, DRS0103, F032113960, LRS02279, M000T32271, M000T32271AM, M000T32271ZE, M000T32272, M000T32272AM, M000T32272ZE, M000T32272ZZ9, M0T32271, M0T32271AM, M0T32271ZE, M0T32272, M0T32272AM, M0T32272ZE, M0T32272ZZ9, MITM0T32272, S0568, S5275S, V7540897, V754089780, V75408978005, V755001780, V75500178004, V7552105, V755210580, V764559080, V7645594, V764559480, 0001 106 405, 0001 106 406, 8EA012528-511, 8EA738258-671, 25-3450, 315.041.112, 0986 021 970, 1986S00652, 3900, 5802 AR, 5802 EV, 5802A, 5802M2, 19000N, 101417, 106438, 113960, 220638, 220638A, 446517, 0001106405, 0001106406, 7540897, 7550017, 7552105, 7552697, 7582309, 7589354, 7616698, 8080278, 11090119, 42021970, 0986021970, 0986021973, 0986021977, 1609870380, 1638135680, 12417540897, 12417550017, 12417552105, 12417552697, 12417567788, 12417582308, 12417582309, 12417589354, 12417589355, 12417616689, 12417616698, 12417617216, 75500178004

  • Normalised article numbler
    cs1417, cst10424, cst35245, drs0103, f032113960, lrs02279, m000t32271, m000t32271am, m000t32271ze, m000t32272, m000t32272am, m000t32272ze, m000t32272zz9, m0t32271, m0t32271am, m0t32271ze, m0t32272, m0t32272am, m0t32272ze, m0t32272zz9, mitm0t32272, s0568, s5275s, v7540897, v754089780, v75408978005, v755001780, v75500178004, v7552105, v755210580, v764559080, v7645594, v764559480, 8ea012528511, 8ea738258671, 1986s00652, 3900, 5802a, 5802ar, 5802ev, 5802m2, 19000n, 101417, 106438, 113960, 220638, 220638a, 253450, 446517, 0001106405, 0001106406, 7540897, 7550017, 7552105, 7552697, 7582309, 7589354, 7616698, 8080278, 11090119, 42021970, 315041112, 0986021970, 0986021973, 0986021977, 1609870380, 1638135680, 12417540897, 12417550017, 12417552105, 12417552697, 12417567788, 12417582308, 12417582309, 12417589354, 12417589355, 12417616689, 12417616698, 12417617216, 75500178004
  • Description

    PSA/Mini Starter motor 12V-0.9kW 12V - 0.9kW, 10/11k A - 60mm, B - 13mm Mini: for vehicles without start-stop function! For Yourrex product order 91-450-2197

    Voltage: 12
    kW: 0.9
    Mounting flange: 64.00
    Drive distance: 13.00
    Mounting hole 4 mm: 9.00
    Mounting hole 3 mm: M8
    Mounting hole 1 mm: 9.00
    Distance / back: 137.00
    Distance / front: 48.50
    Number / teeth: 10
    B+: M8
    Terminal 50: 4.80
    Gear type: GR
    Distance 2: 29.00
    Distance 3: 46.00
    Distance 4: 91.00
    Distance in mm: 124.00
    Rotation: CW
    Total length in mm: 194.00
    Info: A. Measure = 60.00-64.00 mm.
    Number / mounting holes: 4 (2)

    Files

  • Suitable for these vehicles

    • OEM
      CS1417, CST10424, CST35245, DRS0103, F032113960, LRS02279, M000T32271, M000T32271AM, M000T32271ZE, M000T32272, M000T32272AM, M000T32272ZE, M000T32272ZZ9, M0T32271, M0T32271AM, M0T32271ZE, M0T32272, M0T32272AM, M0T32272ZE, M0T32272ZZ9, MITM0T32272, S0568, S5275S, V7540897, V754089780, V75408978005, V755001780, V75500178004, V7552105, V755210580, V764559080, V7645594, V764559480, 0001 106 405, 0001 106 406, 8EA012528-511, 8EA738258-671, 25-3450, 315.041.112, 0986 021 970, 1986S00652, 3900, 5802 AR, 5802 EV, 5802A, 5802M2, 19000N, 101417, 106438, 113960, 220638, 220638A, 446517, 0001106405, 0001106406, 7540897, 7550017, 7552105, 7552697, 7582309, 7589354, 7616698, 8080278, 11090119, 42021970, 0986021970, 0986021973, 0986021977, 1609870380, 1638135680, 12417540897, 12417550017, 12417552105, 12417552697, 12417567788, 12417582308, 12417582309, 12417589354, 12417589355, 12417616689, 12417616698, 12417617216, 75500178004

    • Normalised article numbler
      cs1417, cst10424, cst35245, drs0103, f032113960, lrs02279, m000t32271, m000t32271am, m000t32271ze, m000t32272, m000t32272am, m000t32272ze, m000t32272zz9, m0t32271, m0t32271am, m0t32271ze, m0t32272, m0t32272am, m0t32272ze, m0t32272zz9, mitm0t32272, s0568, s5275s, v7540897, v754089780, v75408978005, v755001780, v75500178004, v7552105, v755210580, v764559080, v7645594, v764559480, 8ea012528511, 8ea738258671, 1986s00652, 3900, 5802a, 5802ar, 5802ev, 5802m2, 19000n, 101417, 106438, 113960, 220638, 220638a, 253450, 446517, 0001106405, 0001106406, 7540897, 7550017, 7552105, 7552697, 7582309, 7589354, 7616698, 8080278, 11090119, 42021970, 315041112, 0986021970, 0986021973, 0986021977, 1609870380, 1638135680, 12417540897, 12417550017, 12417552105, 12417552697, 12417567788, 12417582308, 12417582309, 12417589354, 12417589355, 12417616689, 12417616698, 12417617216, 75500178004
