HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032115830

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 2.0, No./teeth: 13, Rotation: CW

Description

Voltage: 12
kW: 2.0
Mounting flange: 78.00
Drive distance: 18.00
Mounting hole 2 mm: M12-1.75
Mounting hole 1 mm: 10.80
Distance/behind: 177.50
Distance/in front: 55.00
Number/teeth: 13
B+: M8
Position/50: 45
Terminal 50: M6
Gear type: GR
Distance mm: 118.50
Rotation: CW
Total length mm: 232.50
Starter motor type: Start/Stop
Product info: BN
Number/mounting holes: 2 (1)

Files

  • OEM
    cs1578, F032115830, M002T86271, M002T86272, M2T86271, M2T86272, RGO 115830, 1202233, 55578420

  • Normalised article numbler
    cs1578, cst35325, drs0964, f032115830, lrs02715, m002t86271, m002t86272, m2t86271, m2t86272, rgo115830, s5216, 8ea011611831, 3221, 30366n, 220802, 220802a, 254388, 255345, 458889, 1202233, 11040857, 55578420, 130569132, 328073132, 0986029210
  • Description
    Voltage: 12
    kW: 2.0
    Mounting flange: 78.00
    Drive distance: 18.00
    Mounting hole 2 mm: M12-1.75
    Mounting hole 1 mm: 10.80
    Distance/behind: 177.50
    Distance/in front: 55.00
    Number/teeth: 13
    B+: M8
    Position/50: 45
    Terminal 50: M6
    Gear type: GR
    Distance mm: 118.50
    Rotation: CW
    Total length mm: 232.50
    Starter motor type: Start/Stop
    Product info: BN
    Number/mounting holes: 2 (1)

    Files

  • Suitable for these vehicles

    • OEM
      cs1578, F032115830, M002T86271, M002T86272, M2T86271, M2T86272, RGO 115830, 1202233, 55578420

    • Normalised article numbler
      cs1578, cst35325, drs0964, f032115830, lrs02715, m002t86271, m002t86272, m2t86271, m2t86272, rgo115830, s5216, 8ea011611831, 3221, 30366n, 220802, 220802a, 254388, 255345, 458889, 1202233, 11040857, 55578420, 130569132, 328073132, 0986029210
