HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032115637

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 1.0, No./teeth: 9, Rotation: CW

Description

Honda CR-V Starter motor 12V-1.2kW 12V - 1.2kW, 9k A - 75mm, B - 33mm For Yourex product order 91-222-2987

Voltage: 12
kW: 1.0
Mounting flange: 75.00
Drive distance: 33.00
Mounting hole 2 mm: 13.00
Mounting hole 1 mm: 11.00
Distance / back: 150.00
Distance / front: 66.00
Number / teeth: 9
B+: M8
Position/50: 40
Terminal 50: 6.30
Gear type: GR
Mounting bracket: w/
Distance mm: 115.50
Rotation: CW
Total length mm: 229.00
Prod. info: BN
Number / mounting holes: 2 (0)

Files

  • OEM
    cs1456, DSDH6, F032115637, RGO 115637, 1986S00981, 31200-pne-g01, 31200-PNEG01, 115637, 228000-9860, 228000-9861, 228000-9870, 228000-9871, 228000-9872, 428000-4670

  • Normalised article numbler
    cs1456, cst40360, drs0464, dsdh6, dsn1389, f032115637, lrs02264, rgo115637, s6221s, 0986jr1128, 1986s00981, 17962n, 17962r, 31200pneg01, 101456, 115637, 253435, 458674, 8080380, 11040745, 120522092, 322052092, 0986025330, 0986025740, 2280009860, 2280009861, 2280009870, 2280009871, 2280009872, 4280004670
  • Description
    Honda CR-V Starter motor 12V-1.2kW 12V - 1.2kW, 9k A - 75mm, B - 33mm For Yourex product order 91-222-2987

    Voltage: 12
    kW: 1.0
    Mounting flange: 75.00
    Drive distance: 33.00
    Mounting hole 2 mm: 13.00
    Mounting hole 1 mm: 11.00
    Distance / back: 150.00
    Distance / front: 66.00
    Number / teeth: 9
    B+: M8
    Position/50: 40
    Terminal 50: 6.30
    Gear type: GR
    Mounting bracket: w/
    Distance mm: 115.50
    Rotation: CW
    Total length mm: 229.00
    Prod. info: BN
    Number / mounting holes: 2 (0)

    Files

  • Suitable for these vehicles

    • OEM
      cs1456, DSDH6, F032115637, RGO 115637, 1986S00981, 31200-pne-g01, 31200-PNEG01, 115637, 228000-9860, 228000-9861, 228000-9870, 228000-9871, 228000-9872, 428000-4670

    • Normalised article numbler
      cs1456, cst40360, drs0464, dsdh6, dsn1389, f032115637, lrs02264, rgo115637, s6221s, 0986jr1128, 1986s00981, 17962n, 17962r, 31200pneg01, 101456, 115637, 253435, 458674, 8080380, 11040745, 120522092, 322052092, 0986025330, 0986025740, 2280009860, 2280009861, 2280009870, 2280009871, 2280009872, 4280004670
