HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032111115

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 2.2, No./teeth: 11, Rotation: CW

Description

PSA Starter motor 12V-2.2kW 12V - 2.2kW, 11/12k End cover hole: M7 for Yourex product order 91-100-1060 Voltage: 12 kW: 2.2 Mounting flange: 82.00 Drive distance: 29.00 Mounting hole 3 mm: M7 Mounting hole 2 mm: M7 Mounting hole 1 mm: M7 Distance/behind: 214.00 Distance/in front: 69.00 Number/teeth: 11 B+: M8 Position/B+: 20 Thread length mm: 10.00 Position/50: 5 Terminal 50: M5 Gear type: GR Distance 2: 81.00 Distance 3: 81.00 Distance mm: 114.00 Rotation: CW Total length mm: 285.00 Clutch type: Dry Drive type: Steel Product info: BN Waterproof: No Oil sealed: No Number/mounting holes: 3 (3)

Files

  • OEM
    cs361, D9R 90, d9r90, F032111115, RGO 111115, 0001 218 003, 0001 218 020, 0986 010 600, 0986 010 601, 1986S01261, 111115, 0001218003, 0001218020, 0001218620, 1516750R, 91535770, 91535771, 95495849, 95583854, 95619197, 9558385480

  • Normalised article numbler
    cs361, cst10186, cst15147, d9r90, drs0600, drs3078, f032111115, frs628, lrs00328, lrs00650, nd055, qs1350, rgo111115, s0236, str50108, vs281, 8ea726109001, 1138, 1986s01261, 3433, 5802ej, 5802l5, 5802p7, 10361, 11165, 11534, 30649r, 30650r, 103077, 111115, 201189, 220127, 220127a, 251065, 433215, 433326, 580285, 580293, 726127, 0001218003, 0001218020, 0001218620, 1516750r, 1610600, 3010600, 11010600, 42001195, 91535770, 91535771, 95495849, 95583854, 95619197, 220501123, 316008112, 943251099, 943251402, 0986010600, 0986010601, 0986010602, 0986010603, 0986011803, 9558385480, 943251402010, 944280106000
  • Description
    PSA Starter motor 12V-2.2kW 12V - 2.2kW, 11/12k End cover hole: M7 for Yourex product order 91-100-1060 Voltage: 12 kW: 2.2 Mounting flange: 82.00 Drive distance: 29.00 Mounting hole 3 mm: M7 Mounting hole 2 mm: M7 Mounting hole 1 mm: M7 Distance/behind: 214.00 Distance/in front: 69.00 Number/teeth: 11 B+: M8 Position/B+: 20 Thread length mm: 10.00 Position/50: 5 Terminal 50: M5 Gear type: GR Distance 2: 81.00 Distance 3: 81.00 Distance mm: 114.00 Rotation: CW Total length mm: 285.00 Clutch type: Dry Drive type: Steel Product info: BN Waterproof: No Oil sealed: No Number/mounting holes: 3 (3)

    Files

  • Suitable for these vehicles

    • OEM
      cs361, D9R 90, d9r90, F032111115, RGO 111115, 0001 218 003, 0001 218 020, 0986 010 600, 0986 010 601, 1986S01261, 111115, 0001218003, 0001218020, 0001218620, 1516750R, 91535770, 91535771, 95495849, 95583854, 95619197, 9558385480

    • Normalised article numbler
      cs361, cst10186, cst15147, d9r90, drs0600, drs3078, f032111115, frs628, lrs00328, lrs00650, nd055, qs1350, rgo111115, s0236, str50108, vs281, 8ea726109001, 1138, 1986s01261, 3433, 5802ej, 5802l5, 5802p7, 10361, 11165, 11534, 30649r, 30650r, 103077, 111115, 201189, 220127, 220127a, 251065, 433215, 433326, 580285, 580293, 726127, 0001218003, 0001218020, 0001218620, 1516750r, 1610600, 3010600, 11010600, 42001195, 91535770, 91535771, 95495849, 95583854, 95619197, 220501123, 316008112, 943251099, 943251402, 0986010600, 0986010601, 0986010602, 0986010603, 0986011803, 9558385480, 943251402010, 944280106000
