HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032115420

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 1.7, No./teeth: 10, Rotation: CW

Description

Voltage: 12
kW: 1.7
Mount. flange: 60.00
Drive distance: 26.00
Dist./back: 181.50
Dist./front: 59.50
Number/teeth: 10
B+: M8
Position/50: 20
Terminal 50: M6-6.30
Gear type: GR
Depression (dist.) mm: 88.50
Rotation: CW
Total length mm: 255.00
Prod. info: BN
Number/mounting holes: 2 (2)

Files

  • OEM
    a0051518901, D7G15, F00E100228, F032115420, RGO 115420, 1986S00767, 0001115053, 0001115054, 04801516AA, 4801516AA, 0051518901, 2789061600

  • Normalised article numbler
    a0051518901, cst10382, cst15190, d7g15, drs0701, drs0794, drs8170, f00e100228, f032115420, lrs04140, rgo115420, s0460bosch, 1986s00767, 106987, 253095, 254527, 254642, 255304, 438196, 438509, 458275, 458899, 0001115053, 0001115054, 04801516aa, 4801516aa, 11090178, 0051518901, 830599102, 2789061600
  • Description
    Voltage: 12
    kW: 1.7
    Mount. flange: 60.00
    Drive distance: 26.00
    Dist./back: 181.50
    Dist./front: 59.50
    Number/teeth: 10
    B+: M8
    Position/50: 20
    Terminal 50: M6-6.30
    Gear type: GR
    Depression (dist.) mm: 88.50
    Rotation: CW
    Total length mm: 255.00
    Prod. info: BN
    Number/mounting holes: 2 (2)

    Files

  • Suitable for these vehicles

    • OEM
      a0051518901, D7G15, F00E100228, F032115420, RGO 115420, 1986S00767, 0001115053, 0001115054, 04801516AA, 4801516AA, 0051518901, 2789061600

    • Normalised article numbler
      a0051518901, cst10382, cst15190, d7g15, drs0701, drs0794, drs8170, f00e100228, f032115420, lrs04140, rgo115420, s0460bosch, 1986s00767, 106987, 253095, 254527, 254642, 255304, 438196, 438509, 458275, 458899, 0001115053, 0001115054, 04801516aa, 4801516aa, 11090178, 0051518901, 830599102, 2789061600
