HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032111383

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 2.8, No./teeth: 10, Rotation: CW

Description

Voltage: 12
kW: 2.8
Mount. flange: 89.00
Drive distance: 46.00
Mount. hole 3 mm: 11.20
Mount. hole 2 mm: 11.20
Mount. hole 1 mm: 11.20
Distance / back: 250.00
Distance / front: 91.50
Number / teeth: 10
B+: M10
Position / 15a: 20
Terminal 15a: M5
Position / 50: 47
Terminal 50: M5
Gear type: GR
Distance 2: 90.00
Distance 3: 90.00
Distance mm: 127.00
Rotation: CW
Total length mm: 341.50
Clutch type: Wet
Drive type: Steel
Prod. info: BN
Waterproof: No
Oil sealed: Yes
Remarks: Replacing: 28MT.
Number / mount. holes: 3 (0)
