HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032114281

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 1.7, No./teeth: 11, Rotation: CW

Description

Yanmar Starter motor 12V-1.7kW 12V - 1.7kW, 11k A - 95mm, B - 20mm Alternative: 91-678-4815 (1.4kW) For Yourex product order 91-678-4883

Voltage: 12
kW: 1.7
Mounting flange: 95.00
Drive distance: 20.00
Mounting hole 2 mm: 13.00
Mounting hole 1 mm: 13.00
Distance / back: 135.00
Distance / front: 53.00
Number / teeth: 11
B+: M8
Position / 50: 45
Terminal 50: 6.30
Gear type: GR
Distance mm: 120.00
Rotation: CW
Total length mm: 192.00
Prod. info: BN
Number of mounting holes: 2 (0)

Files

  • OEM
    F032114281, K9004758, S114-883, 129242-77010, 1000127525, 1000300231, 1000326334

  • Normalised article numbler
    cst20232, f032114281, k9004758, lrs02449, s114883, s2062, 8ea015642341, 18219n, 18219r, 254121, 11040868, 980533112, 1000127525, 1000300231, 1000326334, 12924277010
  • Description
    Yanmar Starter motor 12V-1.7kW 12V - 1.7kW, 11k A - 95mm, B - 20mm Alternative: 91-678-4815 (1.4kW) For Yourex product order 91-678-4883

    Voltage: 12
    kW: 1.7
    Mounting flange: 95.00
    Drive distance: 20.00
    Mounting hole 2 mm: 13.00
    Mounting hole 1 mm: 13.00
    Distance / back: 135.00
    Distance / front: 53.00
    Number / teeth: 11
    B+: M8
    Position / 50: 45
    Terminal 50: 6.30
    Gear type: GR
    Distance mm: 120.00
    Rotation: CW
    Total length mm: 192.00
    Prod. info: BN
    Number of mounting holes: 2 (0)

    Files

  • Suitable for these vehicles

    • OEM
      F032114281, K9004758, S114-883, 129242-77010, 1000127525, 1000300231, 1000326334

    • Normalised article numbler
      cst20232, f032114281, k9004758, lrs02449, s114883, s2062, 8ea015642341, 18219n, 18219r, 254121, 11040868, 980533112, 1000127525, 1000300231, 1000326334, 12924277010
