HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032114743

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 1.5, No./teeth: 9, Rotation: CW

Description

Voltage: 12
kW: 1.5
Mounting flange: 82.50
Drive distance: 19.00
Mounting hole 2 mm: 13.00
Mounting hole 1 mm: 13.00
Distance / back: 211.00
Distance / front: 60.00
Number / teeth: 9
B+: M8
Position / B+: 60
Position / 50: 15
Terminal 50: M4
Gear type: DD/GR
Distance in millimeters: 105.00
Rotation: CW
Total length mm: 271.00
Number / mounting holes: 2 (0)

Files

  • OEM
    F032114743, 01171482, 1171482, 0001314017, 05710928

  • Normalised article numbler
    cst10270, drs0840, f032114743, lrs00798, 33469, 251092, 01171482, 1171482, 0001314017, 05710928, 11010840, 0986010840, 0986010847
  • Description
    Voltage: 12
    kW: 1.5
    Mounting flange: 82.50
    Drive distance: 19.00
    Mounting hole 2 mm: 13.00
    Mounting hole 1 mm: 13.00
    Distance / back: 211.00
    Distance / front: 60.00
    Number / teeth: 9
    B+: M8
    Position / B+: 60
    Position / 50: 15
    Terminal 50: M4
    Gear type: DD/GR
    Distance in millimeters: 105.00
    Rotation: CW
    Total length mm: 271.00
    Number / mounting holes: 2 (0)

    Files

  • Suitable for these vehicles

    • OEM
      F032114743, 01171482, 1171482, 0001314017, 05710928

    • Normalised article numbler
      cst10270, drs0840, f032114743, lrs00798, 33469, 251092, 01171482, 1171482, 0001314017, 05710928, 11010840, 0986010840, 0986010847
