HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032115842

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 1.0, No./teeth: 8, Rotation: CW

Description

Voltage: 12
kW: 1.0
Mount. flange: 62.00
Drive dist.: 0.00
Mount. hole 3 mm: M10
Dist./back: 142.00
Dist./front: 35.00
No./teeth: 8
B+: M8
Position/50: 50
Terminal 50: M5
Gear type: GR
Dist. 2: 118.00
Dist. 3: 112.00
Dist. mm: 28.00
Rotation: CW
Total length mm: 177.00
Prod. info: BN
No./mounting holes: 3 (3)

Files

  • OEM
    CST35278, DRS0987, F032115842, M000T45371, M000T45371AM, M000T45371ZC, M000T45371ZT, M000T45371ZTDM, M000T45871, M000T45871ZT, M000T45971, M000T45971AM, M000T45971ZT, M000T93381, M000T93381ZZ9, M0T45371, M0T45371AM, M0T45371ZC, M0T45371ZT, M0T45371ZTDM, M0T45871, M0T45871ZT, M0T45971, M0T45971AM, M0T45971ZT, M0T93381, M0T93381ZZ9, S5176, 25-4220, 330.061.082, 570.577.083, 1986S00598, 33355N, 438509, 458887, 11090299, 42028090, 0986028090, 7711368060, 7711368839, 7711497302, 8200298371, 8200520411, 8200538751, 8200584387, 8200584837, 8200665518, 8200665520

  • Normalised article numbler
    cst35278, drs0987, f032115842, m000t45371, m000t45371am, m000t45371zc, m000t45371zt, m000t45371ztdm, m000t45871, m000t45871zt, m000t45971, m000t45971am, m000t45971zt, m000t93381, m000t93381zz9, m0t45371, m0t45371am, m0t45371zc, m0t45371zt, m0t45371ztdm, m0t45871, m0t45871zt, m0t45971, m0t45971am, m0t45971zt, m0t93381, m0t93381zz9, s5176, 1986s00598, 33355n, 254220, 438509, 458887, 11090299, 42028090, 330061082, 570577083, 0986028090, 7711368060, 7711368839, 7711497302, 8200298371, 8200520411, 8200538751, 8200584387, 8200584837, 8200665518, 8200665520
  • Description
    Voltage: 12
    kW: 1.0
    Mount. flange: 62.00
    Drive dist.: 0.00
    Mount. hole 3 mm: M10
    Dist./back: 142.00
    Dist./front: 35.00
    No./teeth: 8
    B+: M8
    Position/50: 50
    Terminal 50: M5
    Gear type: GR
    Dist. 2: 118.00
    Dist. 3: 112.00
    Dist. mm: 28.00
    Rotation: CW
    Total length mm: 177.00
    Prod. info: BN
    No./mounting holes: 3 (3)

    Files

  • Suitable for these vehicles

    • OEM
      CST35278, DRS0987, F032115842, M000T45371, M000T45371AM, M000T45371ZC, M000T45371ZT, M000T45371ZTDM, M000T45871, M000T45871ZT, M000T45971, M000T45971AM, M000T45971ZT, M000T93381, M000T93381ZZ9, M0T45371, M0T45371AM, M0T45371ZC, M0T45371ZT, M0T45371ZTDM, M0T45871, M0T45871ZT, M0T45971, M0T45971AM, M0T45971ZT, M0T93381, M0T93381ZZ9, S5176, 25-4220, 330.061.082, 570.577.083, 1986S00598, 33355N, 438509, 458887, 11090299, 42028090, 0986028090, 7711368060, 7711368839, 7711497302, 8200298371, 8200520411, 8200538751, 8200584387, 8200584837, 8200665518, 8200665520

    • Normalised article numbler
      cst35278, drs0987, f032115842, m000t45371, m000t45371am, m000t45371zc, m000t45371zt, m000t45371ztdm, m000t45871, m000t45871zt, m000t45971, m000t45971am, m000t45971zt, m000t93381, m000t93381zz9, m0t45371, m0t45371am, m0t45371zc, m0t45371zt, m0t45371ztdm, m0t45871, m0t45871zt, m0t45971, m0t45971am, m0t45971zt, m0t93381, m0t93381zz9, s5176, 1986s00598, 33355n, 254220, 438509, 458887, 11090299, 42028090, 330061082, 570577083, 0986028090, 7711368060, 7711368839, 7711497302, 8200298371, 8200520411, 8200538751, 8200584387, 8200584837, 8200665518, 8200665520
