HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032116279

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 1.2, No./teeth: 8, Rotation: CW

Description

Voltage: 12
kW: 1.2
Mount. flange: 74.00
Drive dist.: 26.00
Mount. hole 1 mm: 11.00
Dist./back: 140.00
Dist./front: 59.50
No./teeth: 8
B+: M8
Position/50: 40
Terminal 50: Plug
Gear type: GR
Dist. mm: 129.50
Rotation: CW
Total length mm: 199.00
No./mounting holes: 2 (1)

Files

  • OEM
    F032116279, ts12e200, 1986S01077, 28100-0Q110, 1612093080, 1612350480

  • Normalised article numbler
    cst15299, drs1025, f032116279, s3203s, ts12e200, 8ea011612171, 1986s01077, 255071, 281000q110, 438311, 458734, 11090345, 220540092, 335248092, 0986026490, 1612093080, 1612350480
  • Description
    Voltage: 12
    kW: 1.2
    Mount. flange: 74.00
    Drive dist.: 26.00
    Mount. hole 1 mm: 11.00
    Dist./back: 140.00
    Dist./front: 59.50
    No./teeth: 8
    B+: M8
    Position/50: 40
    Terminal 50: Plug
    Gear type: GR
    Dist. mm: 129.50
    Rotation: CW
    Total length mm: 199.00
    No./mounting holes: 2 (1)

    Files

  • Suitable for these vehicles

    • OEM
      F032116279, ts12e200, 1986S01077, 28100-0Q110, 1612093080, 1612350480

    • Normalised article numbler
      cst15299, drs1025, f032116279, s3203s, ts12e200, 8ea011612171, 1986s01077, 255071, 281000q110, 438311, 458734, 11090345, 220540092, 335248092, 0986026490, 1612093080, 1612350480
