HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032116371

HC-Cargo Starter motor

Technical info:

Voltage: 12, kW: 1.5, No./teeth: 15, Rotation: CW

Description

HC-Cargo Starter motor 12V - 1.5 kW, 15k Voltage: 12 kW: 1.5 Mounting flange: 70.00 Drive distance: 0.50 Mounting hole 3 mm: 8.50 Mounting hole 2 mm: 9.00 Mounting hole 1 mm: 8.50 Distance / back: 171.00 Distance / front: 40.50 Number / teeth: 15 B+: M8 Position / B+: 60 Position / 50: 45 Terminal 50: M6 Gear type: GR Distance 2: 113.00 Distance 3: 75.00 Distance mm: 75.00 Rotation: CW Total length mm: 211.50 Number / mounting holes: 3 (0)

Files

  • OEM
    F032116371, 1241 7645979, 1986S01133, 116371, 438000-0470, 438000-0473, 438000-0474, 438000-0480, 438000-0483, 438000-0484, 7645979, 8570845, 857084505, 12417645979, 12418570845, 12418581690

  • Normalised article numbler
    cst40554, drs0938, f032116371, s6302s, s6341s, 8ea011612921, 1986s01133, 30486n, 30558os, 116371, 255094, 255183, 458941, 458944, 7645979, 8570845, 11090343, 11090442, 42001001, 42026540, 210555153, 210560153, 315062152, 857084505, 0986026530, 0986026540, 4380000470, 4380000473, 4380000474, 4380000480, 4380000483, 4380000484, 12417645979, 12418570845, 12418581690
  • Description
    HC-Cargo Starter motor 12V - 1.5 kW, 15k Voltage: 12 kW: 1.5 Mounting flange: 70.00 Drive distance: 0.50 Mounting hole 3 mm: 8.50 Mounting hole 2 mm: 9.00 Mounting hole 1 mm: 8.50 Distance / back: 171.00 Distance / front: 40.50 Number / teeth: 15 B+: M8 Position / B+: 60 Position / 50: 45 Terminal 50: M6 Gear type: GR Distance 2: 113.00 Distance 3: 75.00 Distance mm: 75.00 Rotation: CW Total length mm: 211.50 Number / mounting holes: 3 (0)

    Files

  • Suitable for these vehicles

    • OEM
      F032116371, 1241 7645979, 1986S01133, 116371, 438000-0470, 438000-0473, 438000-0474, 438000-0480, 438000-0483, 438000-0484, 7645979, 8570845, 857084505, 12417645979, 12418570845, 12418581690

    • Normalised article numbler
      cst40554, drs0938, f032116371, s6302s, s6341s, 8ea011612921, 1986s01133, 30486n, 30558os, 116371, 255094, 255183, 458941, 458944, 7645979, 8570845, 11090343, 11090442, 42001001, 42026540, 210555153, 210560153, 315062152, 857084505, 0986026530, 0986026540, 4380000470, 4380000473, 4380000474, 4380000480, 4380000483, 4380000484, 12417645979, 12418570845, 12418581690
