HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032114313

HC-Cargo Starter motor

Technical info:

Voltage: 24, kW: 2.5, No./teeth: 9, Rotation: CW

Description

Voltage: 24
kW: 2.5
Mounting flange: 82.50
Drive distance: 21.00
Mounting hole 2 mm: 13.00
Mounting hole 1 mm: 13.00
Distance / rear: 211.00
Distance / front: 60.00
Number / teeth: 9
B+: M8
Position / 50: 45
Terminal 50: M4
Gear type: GR
Distance in millimeters: 105.00
Rotation: CW
Total length in millimeters: 272.00
Clutch type: Dry
Drive type: Steel
Number / mounting holes: 2 (0)

Files

  • OEM
    F032114313, 0001219014, 035532044F, 35532044F

  • Normalised article numbler
    cst10607, f032114313, s0264, 254252, 0001219014, 035532044f, 35532044f, 063522190, 063522190140
  • Description
    Voltage: 24
    kW: 2.5
    Mounting flange: 82.50
    Drive distance: 21.00
    Mounting hole 2 mm: 13.00
    Mounting hole 1 mm: 13.00
    Distance / rear: 211.00
    Distance / front: 60.00
    Number / teeth: 9
    B+: M8
    Position / 50: 45
    Terminal 50: M4
    Gear type: GR
    Distance in millimeters: 105.00
    Rotation: CW
    Total length in millimeters: 272.00
    Clutch type: Dry
    Drive type: Steel
    Number / mounting holes: 2 (0)

    Files

  • Suitable for these vehicles

    • OEM
      F032114313, 0001219014, 035532044F, 35532044F

    • Normalised article numbler
      cst10607, f032114313, s0264, 254252, 0001219014, 035532044f, 35532044f, 063522190, 063522190140
