HC-Cargo Starter motor
HC-Cargo Starter motor
Article no.: F032116347

HC-Cargo Starter motor

Technical info:

Voltage: 24, kW: 4.0, No./teeth: 9, Rotation: CW

Description

Voltage: 24
kW: 4.0
Mount. flange: 110.00
Drive distance: 27.00
Mount. hole 3 mm: 12.00/14.00
Mount. hole 2 mm: 12.00
Mount. hole 1 mm: 12.00
Distance / back: 231.00
Distance / front: 74.00
Number / teeth: 9
B+: M10
Position / B+: 60
Terminal 50: M6
Gear type: GR
Distance 2: 103.50
Distance 3: 103.50
Distance mm: 146.00
Rotation: CW
Total length mm: 317.00
Number / mount holes: 3 (0)

Files

  • OEM
    F032116347, 0001231010, 75114529

  • Normalised article numbler
    cst10661, drt1690, f032116347, s0425, str22063, 8ea015642461, 19664n, 220754, 220754a, 861049, 0001231010, 11021690, 75114529, 0986021690, 0986021693
  • Description
    Voltage: 24
    kW: 4.0
    Mount. flange: 110.00
    Drive distance: 27.00
    Mount. hole 3 mm: 12.00/14.00
    Mount. hole 2 mm: 12.00
    Mount. hole 1 mm: 12.00
    Distance / back: 231.00
    Distance / front: 74.00
    Number / teeth: 9
    B+: M10
    Position / B+: 60
    Terminal 50: M6
    Gear type: GR
    Distance 2: 103.50
    Distance 3: 103.50
    Distance mm: 146.00
    Rotation: CW
    Total length mm: 317.00
    Number / mount holes: 3 (0)

    Files

  • Suitable for these vehicles

    • OEM
      F032116347, 0001231010, 75114529

    • Normalised article numbler
      cst10661, drt1690, f032116347, s0425, str22063, 8ea015642461, 19664n, 220754, 220754a, 861049, 0001231010, 11021690, 75114529, 0986021690, 0986021693
