Solenoid
Solenoid
Article no.: F032231919

Solenoid

Technical info:

Voltage: 24, OD mm: 69.00, Total length mm: 160.00, No./mount. holes: 3

Description

Voltage: 24
OD mm: 69.00
Total length mm: 160.00
No./mounting holes: 3
B+: 1/2" UNC
Height/B+: 28.00
Terminal 50/mm: 10-32 UNF
Coil bolt: 1/2" UNC
Coil bolt length: 12.00
No./terminals: 4
Remarks: Dummy terminal: 10-32 UNF. Jump start sheath. Silver contacts. Coil Resistance: Suction Pole = 0.635. Team Coil = 3.150.

Files

  • OEM
    d916a, d921a, F032231919, ZM 2-460, ZM 6-460, 2-460, 6-460, 1115622, 1115627

  • Normalised article numbler
    d916a, d921a, f032231919, snd1272, ss1020, ss1020p, ss1020zm, zm2460, zm6460, 2460, 6460, 7959, 7959sr, 66144, 661445, 1115622, 1115627
  • Description
    Voltage: 24
    OD mm: 69.00
    Total length mm: 160.00
    No./mounting holes: 3
    B+: 1/2" UNC
    Height/B+: 28.00
    Terminal 50/mm: 10-32 UNF
    Coil bolt: 1/2" UNC
    Coil bolt length: 12.00
    No./terminals: 4
    Remarks: Dummy terminal: 10-32 UNF. Jump start sheath. Silver contacts. Coil Resistance: Suction Pole = 0.635. Team Coil = 3.150.

    Files

  • Suitable for these vehicles

    • OEM
      d916a, d921a, F032231919, ZM 2-460, ZM 6-460, 2-460, 6-460, 1115622, 1115627

    • Normalised article numbler
      d916a, d921a, f032231919, snd1272, ss1020, ss1020p, ss1020zm, zm2460, zm6460, 2460, 6460, 7959, 7959sr, 66144, 661445, 1115622, 1115627
